5KVA Silent Air Cooled Diesel Generator With Option ATS For Home Use
| Place of Origin | China |
|---|---|
| Brand Name | TECGEN Air Cooled Diesel Generator |
| Certification | ISO / CE / SASO / SONCAP |
| Model Number | TG |
| Minimum Order Quantity | 1 SET |
| Price | Negotiation |
| Packaging Details | By Carton |
| Delivery Time | 15 working days after received deposit |
| Payment Terms | T/T / L/C |
| Supply Ability | 3000 Units Per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Option | ATS | Output Type | AC Single Phase/Three Phase |
|---|---|---|---|
| Frequency | 50Hz / 60Hz | Speed | 3000RPM / 3600RPM |
| Product | Air Cooled Diesel Generator | Color | Optional |
| Highlight | Silent air cooled diesel generator,5KVA air cooled diesel generator,50Hz air cooled diesel engine generator |
||
Product Description
5KVA Silent Air Cooled Diesel Generator with Option ATS for Home Use
Product Description:
Other Generators' TG model ATS generator is designed with brushless AC alternator, 100% Copper Alternator, AC Brushless Alternator, and low noise and fuel consumption. It offers two speed options at 1500RPM and 1800RPM, and it can output AC Single Phase or Three Phase power. This air cooled diesel generator is reliable and durable, and it is sure to provide you with excellent performance and service.
The TG model ATS generator is guaranteed to provide you with low noise and low fuel consumption, thanks to its brushless AC alternator and 100% Copper Alternator. Its AC brushless alternator ensures a high efficiency performance, and its air cooled system helps keep its noise level down. It is also designed with a durable construction for long-term reliability.
This Other Generators TG model ATS generator is the perfect solution for your power needs. With two speed options and an air cooled diesel generator, it is sure to provide you with reliable and efficient performance. Whether you need AC Single Phase or Three Phase power, this generator is sure to meet your needs.
Features:
- Product Name: Air Cooled Diesel Generator
- Output Type: AC Single Phase/Three Phase
- Option: ATS
- Product: Air Cooled Diesel Generator
- Model Number: TG
- Frequency: 50Hz / 60Hz
Technical Parameters:
| Model(silent type) | DG3500SE | DG5500SE | DG6500SE |
| Rated frequency[Hz] | 50 | ||
| Rated voltage[V] | 220 | ||
| Rated output power[KW/KVA] | 3 | 4.5 | 6 |
| Max output power[KW/KVA] | 3.3 | 5 | 6.5 |
| Rated rotation speed[rpm] | 3000 | ||
| Power factor[cos@] | 1 | ||
| Phase number | Single phase | ||
| Noise level[Db(A)@7m] | 75 | ||
| Excitation mode | Self-excitation brush | ||
| Engine model | Single cylinder,4-stroke,air-cooled,direct injection, diesel engine | ||
| Engine type | SD178F | SD186FA | SD188F |
| Displacement[ml(cu/in)] | 296 | 418 | 456 |
| Starting system | Electric start | ||
| Fuel | 0#(summer) or -10#(winter) -35#(chillness) diesel oil | ||
| Lube | CDgrade or SAE 10W-30,15W-40 | ||
| Low oil pressure alert system | With | ||
| Indications | Voltage--yes and Current --No | ||
| Overall dimension(LxWxH)[mm] | 950x565x770 | ||
| Dry weight[kg] | 100 | 170 | 175 |
| Guarantee period | 1 year | 1 year | 1 year |
| package | carton | carton | carton |
| 20'' container(pcs) | 72 | 72 | 72 |
Applications:
Other Generators, like TECGEN Air Cooled Diesel Generator, Model Number TG from China, having ISO, CE, SASO and SONCAP certification, requires minimum order quantity of 1 SET at negotiated price, with delivery time of 15 working days after received deposit (payment terms – T/T or L/C) and 3000 Units Per Month supply ability. This generator is equipped with brushless Alternator, with speed options of 1500RPM or 1800RPM and output type of AC Single Phase or Three Phase at frequency of 50Hz or 60Hz and optional ATS, all packed in Carton.
Customization:
Other Generators – TECGEN Air Cooled Diesel Generator (TG)
TECGEN's Air Cooled Diesel Generator (TG) is a reliable and high-performance power system designed to provide 100% Copper Alternator, Brushless Dynamo, 100% Copper Generator and Silent Generator. With its ISO / CE / SASO / SONCAP certification, this generator is ideal for commercial, industrial and residential applications. Our generator is available in AC Single Phase/Three Phase with 50Hz / 60Hz frequency, and the option of ATS.
The minimum order quantity is 1 SET, and the price is negotiable. Delivery time is 15 working days after received deposit. Payment terms are T/T/L/C. We can supply 3000 Units per month. Packaging details are by carton.
Support and Services:
Other Generators offers technical support and services to help you get the most out of our products. Our team of experts are ready to provide assistance to ensure a smooth and successful experience with Other Generators. We provide comprehensive technical support services that include:
- 24/7 online support
- Phone support
- Live chat
- Email support
- Troubleshooting
- Product updates
- Installation and setup assistance
