50Hz 1500rpm Deutz Diesel Generators Genset With Exceptional Performance At High Altitudes
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type Of Unit | Open Type | Frequency | 50Hz |
|---|---|---|---|
| Rate Speed | 1500rpm | Voltage | 380/220V |
| Engine Brand | Deutz | Genset Output | 450kW / 500kW |
| Current | 855.4A / 949.6A | Option | Silent Type |
| Highlight | 1500rpm deutz diesel generators,high Performance deutz diesel generators,1500rpm deutz generator |
||
Product Description
Deutz diesel generators 50Hz Deutz genset with exceptional performance at high altitudes
Advantages and characteristics of Huachai Deutz diesel engine generator set
Reliability Rooted in Quality
- Deutz-derived technology & process.
- Imported key parts: crankshaft, crankcase, piston ring.
- ISO & military-grade quality systems.
- Rigorous factory testing.
- Up to 15,000 hours of lifespan.
Compact & Powerful
- Small footprint, big output.
- Unmatched durability.
- Eco-friendly: meets national & European emissions standards.
- High serialization for simplified spare parts management.
- Exceptional performance at high altitudes.
50Hz Deutz Genset TECHNICAL DATA
| Technical Specification: | |||||
| Deutz Diesel Generators Specification | |||||
| Genset Model | TG619DE | TG619DES | TG688DE | TG688DES | |
| Open | Silent | Open | Silent | ||
| Frequency | 50Hz | ||||
| Voltage | 380/220V | ||||
| Phase | 3 Phae, 4 Wire | ||||
| Rate Current | 855.4A | 949.6A | |||
| Prime Power | 450kW / 563kVA | 500kW / 625kVA | |||
| Standby Power | 495kW / 619kVA | 550kW / 688kVA | |||
| Engine Model | BF8M1015CP-LA G5 | HC12V132ZL-LAG1A | |||
| Alternator Model | TGI354S450 | TGI354S500 | |||
| Controller | DEIF SGC-420 | ||||
| Fuel Tank Capacity | 4 Running Hours | ||||
| Weight And Demensions | |||||
| Length (mm) | 3150 | 4600 | 4000 | 5400 | |
| width (mm) | 1500 | 1800 | 1800 | 2100 | |
| Height (mm) | 2100 | 2300 | 2100 | 2300 | |
| Weight (kgs) | 3500 | 4700 | 3800 | 5060 | |
| Deutz Engine Specification | |||||
| Engine Brand | Deutz | ||||
| Engine Model | BF8M1015CP-LA G5 | HC12V132ZL-LAG1A | |||
| Standby power | 560kW | 670 | |||
| Injection | Indirect | Indirect | |||
| Aspiration | Turbocharged | Turbocharged & Intercooled | |||
| No. of cylinders | 8 | 12 | |||
| Bore of Stroke (mm) | 132 x145 | ||||
| Displacement (L) | 15.874 | 23.812 | |||
| Cooling | water | water | |||
| Compression Ratio | 16.5:1 | ||||
| Engine Oil capacity (L) | 22.5 | 36 | |||
| Coolant Capacity ( In radiator) | 21 | 30 | |||
| Governor | Electric | Electric | |||
| Air Filter | Dry Element | Dry Element | |||
| Fuel consumption | @ 50Hz | 50Hz | |||
| 100% Load (L/h) | 123 | 137 | |||
| 75% Load (L/h) | 92 | 103 | |||
| 50% Load (L/h) | 62 | 68 | |||
| 25% Load (L/h) | 31 | 34 | |||
| AC Alternator Specification | |||||
| Brand | Tecgen | Tecgen | |||
| Model | TGI354S450 | TGI354S500 | |||
| Rate Output | 450kW | 500kW | |||
| Pole | 4 | ||||
| Winding Connections | Star | ||||
| Insulation Class | H | ||||
| Enclosure | IP23 | ||||
| Altitude (m) | ≤1000 | ||||
| Voltage Regulator | AVR | ||||
| Steady State Voltage Regulator | 1% | ||||
| Bearing | single | ||||
| Controller System | |||||
| Brand | DEIF | ||||
| Model | SGC-420 | ||||
| Functions | Control with AMF module | ||||
| Static with auto. battery charger | |||||
| Emergency stop push button | |||||
| ATS Connection &RS485 & CANBUS & MPU VERSIONS | |||||
| OPTIONAL EQUIPMENTS | |||||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | |||||
Deutz Genset Functions:
Starting Options: Manual & Self-Start. Self-Start in 15s: Seamless power transition in 15s post commercial power loss.
Intuitive Display: Oil pressure, temp, voltage, current, frequency, power, & alarms at a glance.
Robust Protection: Safeguards against low oil pressure, overheating, high water temp, & short-circuits.
FAQ:
- MOQ, Payment, Delivery?
- MOQ: 1 set.
- Payment: 30% T/T deposit, 70% T/T before delivery. Or 100% L/C, trade assurance, PayPal, Western Union.
- Delivery: 10-15 working days after deposit.
- Export Port?
- Fuzhou, Fujian or as per customer request.
- Spare Parts?
- Regular engine filters (air, water, fuel, oil) for self-maintenance.
- Parts Availability?
- Yes, anytime. Parts dispatched in 3-5 days.
- Customization?
- Voltage, frequency, tank capacity, phase, color: customizable.
- Distribution Inquiry?
- Welcome! We issue authority certs and sign agreements.
