23kVA Yuchai Diesel Generator 18kW Power Solutions For Every Application
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Brand | Yuchai | Fuel Type | Diesel |
|---|---|---|---|
| Type | Diesel Power Generators | Control System | Mebay DC52D |
| Cooling System | Water Cooled | Dimension | L1780 X W840 X H1360mm |
| Frequency | 50Hz | Noise Level | 68dB(A) |
| Power Output | 23kVA | Rated Current | 32.0A |
| Rated Speed | 1500RPM | Starting System | Electric |
| Voltage | 415/240V | Weight | 800 |
| Highlight | 23kVA Yuchai Diesel Generator,Yuchai Diesel Generator 18kW,240V yuchai genset |
||
Product Description
23kVA Yuchai Generators 18kW Power Solutions for Every Application
Standard Features
- Rated Power: 38 kVA – 2750 kVA (30kW – 2200kW)
- Frequency: 50/60 Hz
- Speed: 1500/1800 RPM
- Phase: 3-phase or single-phase
- Voltage: 110 V – 460 V
- Fuel tank: 8 hours operation or more
- Noise level: Below 68 dB at 7 meters
- Environmental temperature: -5ºC ~ +50ºC
- Water tank:50ºC environmental protection water tank
- Diesel engine: diesel, four-stroke, water-cooling
- Alternator: brushless alternator, Stamford, Leroy Somer, Mecc Alte or equivalent
- Controller: Deepsea / ComAp / Smartgen / DATAKOM
- Delivery time: Normal 15 days
- Starting method: Manual or electric start, adjustable
- Packing: Plastic shrink wrap film for FCL Loading
- Export port: Fuzhou Port or according to customer request
Optional accessories include: ATS, water heater, fuel heater, Alternator heater, fuel – water separator - Electrical start system with maintain free battery & engine driven battery charger;
- Residence silencer with flexible connections & elbow;
- Test report, drawings & manuals included
TECHNICAL DATA:
| Technical Specification: | ||
| Generator Set Specification | ||
| Genset Model | TG25YC | TG25YCS |
| Open | Silent | |
| Frequency | 50Hz | |
| Voltage | 415/240V | |
| Phase | 3 | |
| Rate Current | 32.0A | |
| Prime Power | 18kW / 23kVA | |
| Standby Power | 20kW / 25kVA | |
| Engine Model | Yuchai YCD4V12D-35 | |
| Alternator Model | TGI184S18 | |
| Controller | Mebay DC52D | |
| Weight & Dimensions | ||
| Length (mm) | 1780 | 2200 |
| width (mm) | 840 | 980 |
| Height (mm) | 1360 | 1460 |
| Weight (kgs) | 800 | 1150 |
| Engine Specification | ||
| Brand | Yuchai | |
| Engine Model | YCD4V12D-35 | |
| Prime power (kw) | 23 | |
| Injection | Indirect | |
| Aspiration | Turocharged | |
| No. of cylinders | 4 | |
| Bore of Stroke (mm) | 89 x 100 | |
| Displacement (L) | 2 | |
| Cooling | water | |
| Compression Ratio | 17.3:1 | |
| Engine Oil capacity (L) | 4.3 | |
| Coolant Capacity ( In radiator) | 4.3 | |
| Governor | Electric | |
| Air Filter | Dry Element | |
| Fuel consumption | at 50Hz | |
| 100% Load (L/h) | 4.3 | |
| 75% Load (L/h) | 3.3 | |
| 50% Load (L/h) | 2.2 | |
| 25% Load (L/h) | 1.1 | |
| Alternator Specification | ||
| Brand | Tecgen | |
| Model | TGI184S18 | |
| Rate Output (kVA) | 23 | |
| Pole | 4 | |
| Winding Connections | Star | |
| Insulation Class | H | |
| Enclosure | IP23 | |
| Altitude (m) | ≤1000 | |
| Voltage Regulator | AVR | |
| Steady State Voltage Regulator | 1% | |
| Bearing | Single | |
| Controller System | ||
| Brand | Mebay | |
| Model | DC52D | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| ATS Connection | ||
| OPTIONAL EQUIPMENTS | ||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | ||
Yuchai Series Diesel Generating Set:
- Versatile Output Range: Choose from a wide range of 18kW to 2200kW for your power needs.
- Engine Variety: We offer multiple engine types from the 4 cylinder, 6 cylinder, 12 cylinder, 16 cylinder and Yuchai MTU series to match your specific requirements.
- Trusted Manufacturer: These generators are produced by Guangxi Yuchai Machinery Co., Ltd.., known for their quality and reliability.
FAQ
Q: Which port do you often use?
A: We often use Fuzhou Port, but we can also consider other ports as per customer's request.
Q. How do I choose the power?
A.: Please collect information on the total power consumption of your equipment and take the current into consideration when choosing the power of industrial diesel generator.
Q. What is the difference between Prime power and Standby power?
A.: Prime power refers to the continuous power supply for 12 hours, allowing one hour of 10% overload every 12 hours of operation. Standby power is the maximum output limit value for emergency use, and overloading is not allowed.
Q. What about the warranty?
The warranty period is one and a half years or 1500 hours (whichever comes first) from the date of ex-factory. During the warranty period, our company will provide free replacement parts for problems caused by our quality of diesel generator or raw materials, except for the damaged spare parts of the diesel engine caused by customer's incorrect artificial operation. After the expiration of the warranty period, our company provides cost parts maintenance for the generator set.
