Water Cooled Cummins Diesel Generators 35kW 40kVA Gen Power Diesel Generator
| Place of Origin | China |
|---|---|
| Brand Name | Cummins |
| Certification | CE/SONCAP/SASO/SGS |
| Model Number | TG44C |
| Minimum Order Quantity | 1 Unit |
| Price | Negotiation |
| Packaging Details | Plywood case Package or Plastic film package in container |
| Delivery Time | 15-20 working days after received deposit |
| Payment Terms | T/T, L/C |
| Supply Ability | 200 Units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Namee | Cummins Diesel Generator | Genset Type | Open Or Silent |
|---|---|---|---|
| Engine Brand | Cummins | Alternator Brand | Stamford/Leroy Somer/Tecgen |
| Control System | AMF/ATS | Output Type | AC Three Phase |
| Cooling Method | Water Cooling | Ambient Temp | ≤40 C |
| Conditions Of Use | Land Use | Genset Color | Color Is Optional |
| Highlight | Water Cooled Cummins Diesel Generators,35kW Cummins Diesel Generators,40kVA cummins diesel standby generator |
||
Product Description
Water Cooled Diesel Generator Standby 35kW Cummins Diesel Engine Generator Set 40kVA Gen Power Diesel Generator
Products: Global Warranty 40kVA Cummins Diesel Generator Set
Standby Output: 44kVA/35kW
Prime Output: 40kVA/32kW
Genset Supply Scope:
1. Brand new Cummins water cooled diesel engine
2. Brand new Stamford,Leroy somer, Copy Stamford
3. Radiator with engine driven fan mounted on skid.
4. Deepsea,Comap,Harsen,Smartgen Set mounted control panel
5. CHNT,DELIXI,MCCB mounted
6. Anti-vibration mountings as to ensure the compete genset running under stablilization.
7. 24V DC Electric start system and engine driven battery charger, lead-acid type starting batteries
8. Industrial silencers with flexible connects and elbow
9. Base fuel tank, with fuel gauge integrated in the base frame of generating set
10. Test report of generator, Set of drawings and O&M manuals
11.Optional Choice:Soundproof, ATS (automatic transfer switch), AMF panel, Trailer, Parallel system by your extra choose
Specifications:
| Technical Parameter for Diesel Generator | Genset Model | TG44C |
| Prime Power | 40kVA/32kW | |
| Standby Power | 44kVA/35kW | |
| Frequency | 50Hz | |
| Rated Voltage | 380V | |
| Power Factor | 0.8 | |
| Engine Brand | Cummins | |
| Engine Model | 4BT3.9-G1 | |
| Alternator Brand | Stamford | |
| Alternator Model | PI 144J | |
| Engine General Data | Max Output (kW) | 40 |
| Cyl / Arrangement | 4L | |
| Displacement (L) | 3.9 | |
| Air Intake way | Turbo | |
| Bore×Stroke (mm×mm) | 102x120 | |
| Compression Ratio | 16.5:1 | |
| Speed Governor | Mechanical | |
| Fuel Consumption at 100% load(L/H) | 9.3 | |
| Alternator Data | Model | TGI184S-32 |
| Brand | Tecgen Stamford | |
| Rate Output | 40kVA/32kW | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Protection Grade | IP 23 | |
| Optional brand | Leroy Somer, Marathon and Chinese brand Brushless Alternator | |
| Control System | Brand | Smartgen |
| Model | HGM6120N | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| Alarm | ||
| Optional brand | Deepsea, ComAp | |
| Starting Voltage | 24V | |
| Cooling System | Water-cooled, 50℃ radiator with Cooper | |
Feature:
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
(8).50Hz and 60Hz both are available for choice
Guarantee for 18 months or 1500 hours (accord to whichever comes first) from ex-factory date. During the guarantee period, our Tecgen Power will provide the free easy-damaged spare part for problems caused by our quality of production or raw material, except the damageable spare parts of diesel engine caused by customer's incorrect man-made operation. After expiration, our company provides cost spare parts maintenance for gen-set
