14kVA 16kVA Diesel Engine Generator With Automatic Manual Control System For Easy Operation
| Place of Origin | China |
|---|---|
| Brand Name | Yangdong generator |
| Certification | ISO / CE / SASO / CIQ / CO |
| Model Number | TG15YDS & TG18YDS |
| Minimum Order Quantity | 1 Uint |
| Price | Negotiation |
| Packaging Details | Plastic film package or Polywooden Package |
| Delivery Time | 7 working days after received deposit |
| Payment Terms | T/T / L/C |
| Supply Ability | 400 Units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Starting System | Manual | Options | ATS, Super Silent Type, Trailer Mounted |
|---|---|---|---|
| Rated Frequency | 50Hz | Rated Voltage | 220, 230, 240, 380, 400, 415V |
| Control System | Automatic/Manual | Power Range | 9-83kVA |
| Cooling System | Water Cooled | Brand | Yangdong |
| Highlight | 16kVA diesel engine generator,14kVA diesel engine generator,83kVA dg genset |
||
Product Description
14kVA / 16kVA diesel generating set with Automatic/Manual Control System for Easy Operation
Product Description:
Yangdong Genset is a reliable and robust silent generator with efficient power output, making it a perfect choice for any modern application. This diesel generating set is designed for a range of 9-83kVA and provides both manual and automatic control systems. It is designed with a water cooled system to ensure a silent working environment and a long lasting durability. Yangdong Genset is designed to be highly efficient and reliable, making it the perfect choice for a wide range of applications. It is robust and silent, making it ideal for any home or business use. With its powerful performance and reliable output, Yangdong Genset is the perfect choice for anyone looking for a reliable and efficient power generator set.
Features:
- Product Name: Yangdong Genset
- Power: 9-83kVA
- Control System: Automatic/Manual
- Brand: Yangdong
- Options: ATS, Super Silent Type, Trailer Mounted
- Rated Frequency: 50Hz
- Yangdong generator set
- Genset diesel
- Yangdong diesel generator set
Technical Parameters:
| Technical Specification: | ||||
| 14kVA & 16kW Yangdong Diesel DG Genset Specification | ||||
| Genset Model | TG15YD | TG15YDS | TG18YD | TG18YDS |
| Open | Silent | Open | Silent | |
| Frequency | 50Hz | |||
| Voltage | 415/240V | |||
| Phase | 3 | |||
| Rate Current (A) | 25.6 | 29.2 | ||
| Prime Power | 11kW / 14kVA | 13kW / 16kVA | ||
| Standby Power | 12kW / 15kVA | 14kW / 18kW | ||
| Engine Model | YD480D | YND485D | ||
| Alternator Model | TGI164S11 | TGI164S13 | ||
| Controller | Mebay DC52D | |||
| Fuel Tank Capacity | 40L | 40L | ||
| Weight And Dimensions | ||||
| Length (mm) | 1150 | 1700 | 1150 | 1700 |
| width (mm) | 750 | 850 | 750 | 850 |
| Height (mm) | 950 | 1100 | 950 | 1100 |
| Weight (kgs) | 600 | 800 | 650 | 850 |
| Engine Specification | ||||
| Engine Model | YD480D | YND485D | ||
| Prime (kW) | 14 | 17 | ||
| Injection | Indirect | Indirect | ||
| Aspiration | Naturally Aspirated | Naturally Aspirated | ||
| No. of cylinders | 4 | 4 | ||
| Bore of Stroke (mm) | 80 x 90 | 85 x 95 | ||
| Displacement (L) | 1.809 | 2.156 | ||
| Cooling | water | water | ||
| Compression Ratio | 18:1 | 18:1 | ||
| Engine Oil capacity (L) | 5.3 | 5.3 | ||
| Coolant Capacity ( In radiator) | 5.3 | 5.3 | ||
| Governor | Mechanical | Mechanical | ||
| Air Filter | Dry Element | Dry Element | ||
| Fuel consumption | at 50Hz | at 50Hz | ||
| 100% Load (L/h) | 3.3 | 3.9 | ||
| 75% Load (L/h) | 2.5 | 2.95 | ||
| 50% Load (L/h) | 1.7 | 1.97 | ||
| 25% Load (L/h) | 0.83 | 0.98 | ||
| Alternator Specification | ||||
| Brand | Tecgen | Tecgen | ||
| Model | TGI164S11 | TGI164S13 | ||
| Rate Output (kVA) | 14 | 16 | ||
| Pole | 4 | |||
| Winding Connections | Star | |||
| Insulation Class | H | |||
| Enclosure | IP23 | |||
| Altitude (m) | ≤1000 | |||
| Voltage Regulator | AVR | |||
| Steady State Voltage Regulator | 1% | |||
| Bearing | single | |||
| Controller System | ||||
| Brand | Mebay | |||
| Model | DC52D | |||
| Functions | Control with AMF module | |||
| Static with auto. battery charger | ||||
| Emergency stop push button | ||||
| ATS Connection | ||||
| OPTIONAL EQUIPMENTS | ||||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | ||||
Applications:
Yangdong Genset is an AC electric generator powered by Yangdong diesel engine and generator set, providing reliable power for a wide variety of applications. It is designed and manufactured to meet the strictest standards of quality and safety, with certification such as ISO, CE, SASO, CIQ, and CO. With a minimum order quantity of one unit, this diesel genset is offered at competitive prices and can be delivered within 7 working days after receiving deposit. Available payment terms include T/T and L/C. The generator set has a rated frequency of 50Hz and can have a voltage of 220, 230, 240, 380, 400, or 415V. It has an automatic or manual control system and a water-cooled cooling system, and comes with different options such as ATS, Super Silent Type, and Trailer Mounted. With a supply capacity of up to 400 Units per month, Yangdong Genset is an ideal solution for various commercial and industrial applications.
Customization:
Yangdong Genset
Brand Name: Yangdong generator
Model Number: TG15YDS & TG18YDS
Place of Origin: China
Certification: ISO / CE / SASO / CIQ / CO
Minimum Order Quantity: 1 Uint
Price: Negotiation
Packaging Details: Plastic film package or Polywooden Package
Delivery Time: 7 working days after received deposit
Payment Terms: T/T / L/C
Supply Ability: 400 Units per month
Cooling System: Water Cooled
Control System: Automatic/Manual
Brand: Yangdong
Starting System: Manual
Power prime: 14kVA & 16kVA
Keyword: power generator set, AC electric generator, diesel generating set
Packing and Shipping:
Packaging and Shipping for Yangdong Genset
Yangdong Genset products are packaged and shipped according to the customer's needs. We use high-quality packing materials to ensure that the products are safe and secure during the transportation process. We also offer a variety of shipping options to meet the customer's specific requirements, such as air freight, sea freight, express and so on.
FAQ:
- Q: What is the Brand Name of Yangdong Generator?
- A: The Brand Name of Yangdong Generator is Yangdong.
- Q: What is the Model Number of Yangdong Generator?
- A: The Model Number of Yangdong Generator is TG15YDS & TG18YDS.
- Q: Where is the Place of Origin of Yangdong Generator?
- A: The Place of Origin of Yangdong Generator is China.
- Q: What is the Certification of Yangdong Generator?
- A: The Certification of Yangdong Generator is ISO / CE / SASO / CIQ / CO.
- Q: What is the Minimum Order Quantity of Yangdong Generator?
- A: The Minimum Order Quantity of Yangdong Generator is 1 Uint.
