Prime Power 220KW YTO Diesel 275 Kva Generator With Water Heater Automatic Control System
| Place of Origin | China |
|---|---|
| Brand Name | YTO generator |
| Certification | ISO / CE / SASO / CIQ / CO |
| Model Number | TGYT |
| Minimum Order Quantity | 1 Uint |
| Price | Negotiation |
| Packaging Details | Plastic film package or Plywood case |
| Delivery Time | 15 working days after received deposit |
| Payment Terms | T/T / L/C |
| Supply Ability | 400 Units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Alternator Brand | Tecgen Stamford | Options | ATS, Water Heater, Trailer Mounted |
|---|---|---|---|
| Power | 30-480kVA | Control System | Automatic |
| Cooling System | Water Cooled | Rated Voltage | 220, 230, 240, 380, 400, 415,440,460,480V |
| Brand | YTO | Rated Frequency | 50Hz/60Hz |
| Highlight | Diesel 275 kva generator,YTO 275 kva generator,220KW dg generator set |
||
Product Description
Prime Power 275KVA /220KW YTO Diesel Genset with Water Heater and Automatic Control System
Product Description:
YTO Genset is a silent diesel generator set powered by YTO diesel engine and equipped with Tecgen Stamford Alternator. It is a water cooled system with several options such as Automatic Transfer Switch(ATS), water heater and trailer mounted. It is designed to be reliable and efficient, providing a reliable power supply when needed. The diesel genset has a wide range of applications including commercial, industrial, residential and agricultural. It is easy to install and maintain, making it an ideal choice for users who need a reliable power source. It is a cost-effective and eco-friendly option for those looking for a reliable and cost-efficient power source.
Features:
1, Output range: 5kVA to 3000kVA Heavy Duty diesel generator.
2, Different brands of engine, alternator and controller as options
3, Coupled with Stamford alternator, Leroy Somer alternator, Marathon alternator or Tecgen Power alternator
4, Open type, silent type, super silent type or mobile type generator.
5, CE, ISO9001-2008, SONCAP, SASO and SGS certified
6, Starter System with maintenance-free battery
7, Control Panel with Key Start (Power Switch)
8, With 100% fire-resistant sound attenuating sponge
9, 10% of rate output of overload for 1hours in every 12hours
10, Spare parts are easy to get from worldwide market with much cheaper price
11, Perfect after-service network
12, Both 50Hz and 60Hz
13, Chint circuit breaker
14, Three-phase output meets differing requirements
15, ATS ( auto transfer switch for city power and generator power ) / AMF (auto mains failure) /parallel running for option
16, Large fuel tank ensure continuous running.
17, Anti-Vibration Mounted
18, Industrial silencer and flexible exhaust hose
19, 0-110% load test for each unit before delivery
20, Guarantee for 18 months or 1500 hours (accord to whichever comes first) from ex-factory date
Technical Parameters:
Specifications:
| Technical Parameter for Diesel Generator | Genset Model | TG300YT |
| Prime Power | 275kVA/220kW | |
| Standby Power | 303kVA/242kW | |
| Frequency | 50Hz | |
| Rated Voltage | 400V | |
| Power Factor | 0.8 | |
| Engine Brand | YTO | |
| Engine Model | YM6S4LF-15 | |
| Alternator Brand | Tecgen | |
| Alternator Model | TGI314S-220 | |
| Engine General Data | Engine Power(kW) | 252 |
| Cyl / Arrangement | 6L | |
| DSPL(L) | 9.726 | |
| Bore×Stroke (mm×mm) | 126 x130 | |
| Speed Governor | Electric | |
| Fuel Consumption (g/kw.h)) | 205 | |
| Alternator Data | Model | TGI314S-220 |
| Brand | Tecgen Stamford | |
| Rate Output | 275kVA/220kW | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Protection Grade | IP 23 | |
| Control System | Brand | Smartgen |
| Model | HGM6120N | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| Alarm | ||
| Optional brand | Deepsea, ComAp |
Applications:
Yangdong Genset is a brand of reliable and high quality soundproof generators, silent generators and silent generator sets. The model number for Yangdong Genset is TGYT and it is made in China with strict ISO / CE / SASO / CIQ / CO certifications. It is available in minimum order quantity of one unit and the price is negotiable. The generator is packed in plastic film package or plywood case and delivered within 15 working days after receiving the deposit. Payment terms are T/T or L/C. It has a supply ability of 400 units per month.
Yangdong Genset is powered by Tecgen Stamford alternator with a range from 30-480kVA. It has a water cooled system and also offers features such as ATS, Water Heater and Trailer Mounted. It has a low noise level and provides great performance. It is an excellent choice for power generation in various applications, from residential to industrial.
Customization:
Yangdong Genset offers high quality and reliable AC electric generator sets with the brand name YTO Generator. It features model number TGYT, and it is certified with ISO, CE, SASO, CIQ and CO. It is water cooled and the alternator brand is Tecgen Stamford. It is available in power range between 30 to 480kVA, and rated frequency of 50Hz/60Hz. It also offers ATS, water heater and trailer mounted options. The minimum order quantity is 1 unit, and the price is negotiable. The packaging details include plastic film package or plywood case, and the delivery time is 15 working days after received deposit. The payment terms are T/T or L/C, and the supply ability is 400 units per month.
Support and Services:
Yangdong Genset offers a wide range of technical support and services to meet the needs of our customers. Our technical support and services include:
- 24/7 Support hotline
- On-site service and repair
- Preventative maintenance plans
- Parts and accessories
- Training and certification
- Online troubleshooting
