50HZ 120KW Diesel YTO Generators With Water Cooling System Automatic Control
| Place of Origin | China |
|---|---|
| Brand Name | YTO generator |
| Certification | ISO / CE / SASO / CIQ / CO |
| Model Number | TGYT |
| Minimum Order Quantity | 1 Uint |
| Price | Negotiation |
| Packaging Details | Plastic film package or Plywood case |
| Delivery Time | 15 working days after received deposit |
| Payment Terms | T/T / L/C |
| Supply Ability | 400 Units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Brand | YTO | Rated Frequency | 50Hz/60Hz |
|---|---|---|---|
| Power | 30-480kVA | Options | ATS, Water Heater, Trailer Mounted |
| Cooling System | Water Cooled | Control System | Automatic |
| Rated Voltage | 220, 230, 240, 380, 400, 415,440,460,480V | Alternator Brand | Tecgen Stamford |
| Highlight | Diesel yto generators,120KW yto generators,50HZ 120kw generator |
||
Product Description
50HZ 120KW YTO Diesel Genset with Water Cooling System Automatic Control
Product Description:
Yangdong Genset is a diesel generating set (diesel genset) with a silent diesel generator set from YTO. It is equipped with an automatic control system and a water-cooled cooling system. It has a rated power of 30-480kVA and a rated frequency of 50Hz/60Hz.
Yangdong Genset features low noise, low fuel consumption and high reliability. It has a compact structure and is easy to maintain. With its advanced design, it is suitable for both continuous and standby operation.
The Yangdong Genset provides a complete power solution for residential, commercial and industrial applications. It is designed to meet the most stringent environmental requirements and is ideal for the continuous and reliable operation of your business.
Features:
- Product Name: YTO Genset
- Cooling System: Water Cooled
- Options: ATS, Water Heater, Trailer Mounted
- Power: 30-480kVA
- Brand: YTO
- Control System: Automatic
- Generator Type: AC electric generator, genset diesel engine
Technical Parameters:
| Technical Parameter for Diesel Generator | Genset Model | TG165YT |
| Prime Power | 150kVA/120kW | |
| Standby Power | 165kVA/132kW | |
| Frequency | 50Hz | |
| Rated Voltage | 400V | |
| Power Factor | 0.8 | |
| Engine Brand | YTO | |
| Engine Model | LR6B3L-15 | |
| Alternator Brand | Tecgen | |
| Alternator Model | TGI274S-120 | |
| Engine General Data | Engine Power(kW) | 138 |
| Cyl / Arrangement | 6L | |
| DSPL(L) | 6.87 | |
| Bore×Stroke (mm×mm) | 108 x125 | |
| Speed Governor | Electric | |
| Fuel Consumption (g/kw.h)) | 202 | |
| Alternator Data | Model | TGI274S-120 |
| Brand | Tecgen Stamford | |
| Rate Output | 150kVA/120kW | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Protection Grade | IP 23 | |
| Control System | Brand | Smartgen |
| Model | HGM6120N | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| Alarm | ||
| Optional brand | Deepsea, ComAp |
Applications:
Yangdong Genset is a silent diesel generator set powered by YTO, with model number TGYT. It is certified by ISO / CE / SASO / CIQ / CO and has a minimum order quantity of 1 unit. The price is negotiable and the packaging is either plastic film package or plywood case. Delivery time is 15 working days after receiving the deposit and payment terms are T/T / L/C. The supply ability is 400 units per month and there are many options available, such as ATS, water heater, and trailer mounted. The rated frequency is 50 Hz / 60 Hz and the control system is automatic. The rated voltage is 220, 230, 240, 380, 400, 415, 440, 460, 480V and the power range is from 30-480 KVA. Yangdong Genset is a reliable, high-performance power generator set with excellent brand reputation.
Customization:
Yangdong Genset – Silent Diesel Generator Set
Yangdong Genset is a reliable and efficient silent diesel generator set with a brand name of YTO generator. It is certified by ISO / CE / SASO / CIQ / CO and is available in a minimum order quantity of 1 unit. It is supplied with the Tecgen Stamford alternator and options such as ATS, Water Heater, and Trailer Mounted. The rated voltage of this generator set is 220, 230, 240, 380, 400, 415,440,460,480V with a power range of 30-480kVA. It is packaged with plastic film package or Plywood case. Delivery can be completed within 15 working days after received deposit and Payment Terms include T/T or L/C. Its supply ability is 400 Units per month.
Support and Services:
YTO Genset Technical Support and Service
YTO Genset provides a comprehensive range of services and technical support to ensure that your machine is running smoothly and efficiently.
We offer professional technical support and service, including:
- On-site technical support and maintenance
- Diagnosis and repair of faults
- Advisory services on system design and installation
- Spare parts supply
- Consultancy on system operations and maintenance
