1 / 3 Phase Dynamo AC Double Bearing Alternator Single Bearing 100% Copper Alternator
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Winding | 100% Copper | Speed | 1500RPM / 1800RPM |
|---|---|---|---|
| Frequency | 50Hz / 60Hz | Phase | Single / Three Phase |
| Product | TECGEN Brushless Alternator | Type | Brushless |
| Bearing | Single/Double Bearing | ||
| Highlight | AC double bearing alternator,Dynamo double bearing alternator,3 Phase single bearing alternator |
||
Product Description
1/3phase double bearing dynamo ac alternator Single Bearing 100% Copper Alternator
Product Description:
Other Generators presents the TECGEN Brushless Alternator, Model TGI. This 100% AC Alternator provides an efficient and reliable power source for a variety of applications. With frequency ratings of 50Hz or 60Hz, this Brush Dynamo has a single or double bearing design and 100% copper winding for superior performance. The STC Brush Alternator offers high-end features and reliable operation in even the most demanding environments. This product is a must-have for anyone looking for an efficient and reliable power source.
Features:
- Product Name: Other Generators
- Type: Brushless
- Speed: 1500RPM / 1800RPM
- Winding: 100% Copper
- Phase: Single / Three Phase
- Product: TECGEN Brushless Alternator
- ST/STC alternator: Yes
- Generator / Alternator: Yes
- STC Brush Alternator: Yes
Technical Parameters:
Alternator Rate power: 6.5-1000KVA
| Model | Prime Output (1500rpm/50Hz) 400V | Prime Output (1800rpm/60Hz) 440V | ||
| KVA | KW | KVA | KW | |
| TGI164A | 8.1 | 6.5 | 10.2 | 8.2 |
| TGI164B | 11 | 8.8 | 13.8 | 11 |
| TGI164C | 13.5 | 10.8 | 16.9 | 13.5 |
| TGI164D | 16 | 12.8 | 20 | 16 |
| TGI184E | 22.5 | 18 | 28.8 | 23 |
| TGI184F | 27.5 | 22 | 34.4 | 27.5 |
| TGI184G | 31.3 | 24 | 37.5 | 30 |
| TGI184H | 37.5 | 30 | 46.9 | 37.5 |
| TGI184J | 40 | 32 | 50 | 40 |
| TGI224C | 42.5 | 34 | 52.5 | 42 |
| TGI224D | 50 | 40 | 62.5 | 50 |
| TGI224E | 60 | 48 | 70 | 56 |
| TGI224F | 72.5 | 58 | 87.5 | 70 |
| TGI224G | 85 | 68 | 97.5 | 78 |
| TGI274C | 100 | 80 | 117.5 | 94 |
| TGI274D | 120 | 96 | 137.5 | 110 |
| TGI274E | 140 | 112 | 167.5 | 134 |
| TGI274F | 160 | 128 | 190 | 152 |
| TGI274G | 180 | 144 | 218.5 | 174.8 |
| TGI274H | 200 | 160 | 245 | 196 |
| TGI274J | 230 | 184 | 281 | 224.8 |
| TGI274K | 250 | 200 | 299 | 239.2 |
| TGI314C | 250 | 200 | 294 | 235 |
| TGI314D | 295 | 236 | 350 | 280 |
| TGI314E | 325 | 260 | 394 | 315 |
| TGI314F | 380 | 304 | 456 | 365 |
| TGI354C | 450 | 360 | 550 | 440 |
| TGI354D | 500 | 400 | 594 | 475 |
| TGI354E | 600 | 480 | 713 | 570 |
| TGI354F | 670 | 536 | 775 | 620 |
Support and Services:
Other Generators provides technical support and services to our customers to ensure their satisfaction. Our technical support team is available 24/7 and can be contacted via email, phone, and live chat. We provide troubleshooting assistance, product installation, and repair services. We also offer product upgrades and system maintenance. Additionally, we provide access to our online knowledge base and tutorial videos. If you are not satisfied with your product, we offer a 30-day money-back guarantee.
