TECGEN 6.5 To 1000kva Brushless AC Alternator Single Double Bearing

  • TECGEN 6.5 To 1000kva Brushless AC Alternator Single Double Bearing
  • TECGEN 6.5 To 1000kva Brushless AC Alternator Single Double Bearing
  • TECGEN 6.5 To 1000kva Brushless AC Alternator Single Double Bearing
  • TECGEN 6.5 To 1000kva Brushless AC Alternator Single Double Bearing
Place of Origin China
Brand Name TECGEN Brushless Alternator
Certification ISO / CE / SASO / SONCAP
Model Number TGI
Minimum Order Quantity 1 SET
Price Negotiation
Packaging Details Standard export package
Delivery Time 10 Working Days
Payment Terms T/T / L/C
Supply Ability 2000 Units Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Bearing Single/Double Bearing Phase Single / Three Phase
Product TECGEN Brushless Alternator Frequency 50Hz / 60Hz
Winding 100% Copper Speed 1500RPM / 1800RPM
Type Brushless
Highlight

1000kva brushless ac alternator

,

6.5kva brushless ac alternator

,

TECGEN brushless alternator generator
Leave a Message
Product Description

TECGEN Brushless Alternator 6.5 to 1000kva Brushless AC Alternator

Product Description:

Other Generators is a TECGEN Brushless Alternator, with 100% Copper winding, Single/Double Bearing, 50Hz/60Hz frequency and model number TGI. This brushless dynamo generator is used to produce power with ST/STC alternator and ST/STC Dynamo Generator. It is a reliable and high efficient product for its 100% copper winding, single/double bearing and accurate frequency. What’s more, it features low noise and long life, which can provide sustainable and stable power for your life and work.



Features:

ALTERNATOR TECHNICAL PERFORMANCCE:
1-Adjusting rate of stable voltage ±0.5%
2-Adjusting rate of instant voltage: ≥-15% ~ ≤+20%
3-Adjusting range of voltage: ≥±25%
4-Insulation class: H
5-Constant working type: s1
6-Protection class: IP23

Technical Parameters:

Model Prime Output (1500rpm/50Hz) 400V Prime Output (1800rpm/60Hz) 440V
  KVA KW KVA KW
TGI164A 8.1 6.5 10.2 8.2
TGI164B 11 8.8 13.8 11
TGI164C 13.5 10.8 16.9 13.5
TGI164D 16 12.8 20 16
TGI184E 22.5 18 28.8 23
TGI184F 27.5 22 34.4 27.5
TGI184G 31.3 24 37.5 30
TGI184H 37.5 30 46.9 37.5
TGI184J 40 32 50 40
TGI224C 42.5 34 52.5 42
TGI224D 50 40 62.5 50
TGI224E 60 48 70 56
TGI224F 72.5 58 87.5 70
TGI224G 85 68 97.5 78
TGI274C 100 80 117.5 94
TGI274D 120 96 137.5 110
TGI274E 140 112 167.5 134
TGI274F 160 128 190 152
TGI274G 180 144 218.5 174.8
TGI274H 200 160 245 196
TGI274J 230 184 281 224.8
TGI274K 250 200 299 239.2
TGI314C 250 200 294 235
TGI314D 295 236 350 280
TGI314E 325 260 394 315
TGI314F 380 304 456 365
TGI354C 450 360 550 440
TGI354D 500 400 594 475
TGI354E 600 480 713 570
TGI354F 670 536 775 620

Applications:

The TECGEN Brushless Alternator is designed to provide reliable and efficient power generation for a variety of applications. This 100% copper alternator is designed with a single/double bearing and a brushless design for greater efficiency and durability. It also has a high-quality stator and rotor, ensuring superior performance and extended life. The TGI model is certified to ISO / CE / SASO / SONCAP standards and is available with a minimum order quantity of one set. Packaging is available in standard export packages and delivery is available in 10 working days. Prices are negotiable and 2000 units per month are available. Payment terms are accepted via T/T or L/C.
The TECGEN Brushless Alternator is an ideal choice for a variety of applications. Whether it is providing reliable power generation in the home or powering heavy duty machinery in industrial settings, the STC Brush Alternator is a reliable and efficient option. The 100% copper dynamo offers superior performance and extended life, making it a great choice for any application. With its brushless design, this alternator generator offers greater efficiency and durability, making it a great choice for any power generation need.
TECGEN 6.5 To 1000kva Brushless AC Alternator Single Double Bearing 0

Customization:

TECGEN Brushless Alternator

Brand Name: TECGEN Brushless Alternator
Model Number: TGI
Place of Origin: China
Certification: ISO/CE/SONCAP/SASO
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Standard export package
Delivery Time: 10 Working Days
Payment Terms: T/T/L/C
Supply Ability: 2000 Units Per Month
Speed: 1500RPM/1800RPM
Bearing: Single/Double Bearing
Winding: 100% Copper

TECGEN 100% Copper Alternator





Support and Services:

  • Technical Support: We provide a variety of technical support options, including online FAQs, email support, and telephone support.
  • Service: We offer a variety of services for our Other Generators products, including installation, repair, and maintenance.
