Stamford Single Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator

  • Stamford Single Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator
  • Stamford Single Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator
  • Stamford Single Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator
Place of Origin China
Brand Name TECGEN Brushless Alternator
Certification ISO / CE / SASO / SONCAP
Model Number TGI
Minimum Order Quantity 1 SET
Price Negotiation
Packaging Details Standard export package
Delivery Time 10 Working Days
Payment Terms T/T / L/C
Supply Ability 2000 Units Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Bearing Single/Double Bearing Product TECGEN Brushless Alternator
Phase Single / Three Phase Winding 100% Copper
Type Brushless Frequency 50Hz / 60Hz
Speed 1500RPM / 1800RPM
Highlight

100kva brushless alternator

,

85kva brushless alternator

,

50kva generator brushless alternator
Leave a Message
Product Description

Stamford Single/Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator

Product Description:

Other Generators presents its 100% copper winding Brushless Alternator model TGI. This single or three phase AC Alternator is available in two speed options - 1500RPM and 1800RPM. This 100% Brush Alterantor is designed to provide optimal performance and is ideal for a variety of applications. Our Brushless Alternator is also known for its reliability and durability, making it the perfect choice for all your power needs.



Features:

  • Product Name: Other Generators
  • Model Number: TGI
  • Product: TECGEN Brushless Alternator
  • Phase: Single / Three Phase
  • Frequency: 50Hz / 60Hz
  • Bearing : Single/Double Bearing
  • 100% Brush Alterantor
  • 100% AC Alternator
  • Brush Dynamo Alternator



Alternator Rate power: 6.5-1000KVA



Model Prime Output (1500rpm/50Hz) 400V Prime Output (1800rpm/60Hz) 440V
KVA KW KVA KW
TGI164A 8.1 6.5 10.2 8.2
TGI164B 11 8.8 13.8 11
TGI164C 13.5 10.8 16.9 13.5
TGI164D 16 12.8 20 16
TGI184E 22.5 18 28.8 23
TGI184F 27.5 22 34.4 27.5
TGI184G 31.3 24 37.5 30
TGI184H 37.5 30 46.9 37.5
TGI184J 40 32 50 40
TGI224C 42.5 34 52.5 42
TGI224D 50 40 62.5 50
TGI224E 60 48 70 56
TGI224F 72.5 58 87.5 70
TGI224G 85 68 97.5 78
TGI274C 100 80 117.5 94
TGI274D 120 96 137.5 110
TGI274E 140 112 167.5 134
TGI274F 160 128 190 152
TGI274G 180 144 218.5 174.8
TGI274H 200 160 245 196
TGI274J 230 184 281 224.8
TGI274K 250 200 299 239.2
TGI314C 250 200 294 235
TGI314D 295 236 350 280
TGI314E 325 260 394 315
TGI314F 380 304 456 365
TGI354C 450 360 550 440
TGI354D 500 400 594 475
TGI354E 600 480 713 570
TGI354F 670 536 775 620


Applications:

The TECGEN Brushless Alternator is an AC brush alternator from China that is perfect for any generator or alternator application. This superior product is designed to provide maximum output and durability, making it the ideal choice for a wide range of industrial and commercial applications. It is certified by ISO/CE/SASO/SONCAP and comes with a minimum order quantity of one set. The price is negotiable and it is delivered in a standard export package within 10 working days. Payment terms are flexible, with buyers having the option of either T/T or L/C. Our manufacturing capacity is 2000 units per month, and the alternator comes with single/double bearing, 100% copper winding, 1500RPM/1800RPM speed, and single/three-phase options.



Stamford Single Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator 0Stamford Single Double Bearing 11kva 16kva 27.5kva 37.5kva 40kva 50kva 85kva 100kva Brushless Alternator 1

Customization:

TECGEN Brushless Alternator

Model Number: TGI

Place of Origin: China

Certification: ISO / CE / SASO / SONCAP

Minimum Order Quantity: 1 SET

Price: Negotiation

Packaging Details: Standard export package

Delivery Time: 10 Working Days

Payment Terms: T/T / L/C

Supply Ability: 2000 Units Per Month

Features:
100% Copper Alternator, 100% Brush Alterantor, Generator / Alternator
Phase: Single / Three Phase
Frequency: 50Hz / 60Hz
Type: Brushless
Speed: 1500RPM / 1800RPM
Bearing : Single/Double Bearing



Support and Services:

Technical Support and Service for Other Generators

We provide technical support and services for Other Generators customers. We strive to ensure customers are able to maximize their product's performance and reliability. Our technical support team is available to answer questions about product features, installation, and troubleshooting. We offer a variety of support options including online support, phone support, and on-site services. Additionally, we provide regular software and firmware updates to ensure customers are always using the latest version of the product.
