15kVA 18kVA 20kVA Brushless Synchronous Alternator 22kVA Brushless Dynamo For Genset Applications

  • 15kVA 18kVA 20kVA Brushless Synchronous Alternator 22kVA Brushless Dynamo For Genset Applications
  • 15kVA 18kVA 20kVA Brushless Synchronous Alternator 22kVA Brushless Dynamo For Genset Applications
  • 15kVA 18kVA 20kVA Brushless Synchronous Alternator 22kVA Brushless Dynamo For Genset Applications
Place of Origin China
Brand Name TECGEN Brushless Alternator
Certification ISO / CE / SASO / SONCAP
Model Number TGI 184 Series
Minimum Order Quantity 1 SET
Price Negotiation
Packaging Details Plastic film package or Polywooden Package
Delivery Time 10 Working Days
Payment Terms T/T / L/C
Supply Ability 10000 Units Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Frequency 50Hz / 60Hz Alternator Output Type A.C. Synchronous Alternator
Product TECGEN Brushless Alternator Speed 1500RPM / 1800RPM
Bearing Single/Double Bearing Type Brushless
Winding 100% Copper
Highlight

20kVA Brushless Synchronous Alternator

,

Brushless Synchronous Alternator 22kVA

,

15kVA brushless dynamo
Leave a Message
Product Description

Brushless synchronous alternator 15kVA 18kVA 20kVA 22kVA brushless dynamo for genset Applications

Product Description:

Other Generators is a brushless dynamo designed to provide a reliable source of AC synchronous power. It is made with 100% copper windings for maximum durability and efficiency. With its brushless design, this generator has a high speed of 1500RPM or 1800RPM, allowing it to produce high-quality power quickly. This generator is an excellent choice for those who need a reliable and efficient source of AC synchronous power. It is also suitable for both residential and commercial applications. The 100% copper windings provide maximum efficiency, and the brushless design ensures a long-lasting and durable generator. With its high speed and reliable performance, Other Generators is an ideal choice for any application.



Features:

  • Product Name: Other Generators
  • Alternator Output type: A.C. Synchronous Alternator
  • Bearing: Single/Double Bearing
  • Type: Brushless Dynamo, AC Brushless Alternator
  • Frequency: 50Hz / 60Hz
  • Speed: 1500RPM / 1800RPM
  • Material: 100% Copper Alternator
15kVA 18kVA 20kVA Brushless Synchronous Alternator 22kVA Brushless Dynamo For Genset Applications 0

Technical Parameters:

Model Prime Stand-by stator Single bearing Packed
400V/50Hz length size/Weight
KW KVA KW KVA L= mm m³ KGS
TGI-164A 6.5 8 7 9 65mm 430*440*490 0.10 93
TGI-164B 8.8 11 10 12 80mm 430*440*490 0.10 97
TGI-164C 10.8 14 12 15 100mm 460*440*490 0.10 106
TGI-164D 12.8 16 14 18 115mm 460*440*490 0.10 112
TGI-184ES 15 19 17 21 135mm 520*490*510 0.13 130
TGI-184E 18 23 20 25 150mm 520*490*510 0.13 138
TGI-184F 22 28 24 30 190mm 610*490*510 0.16 161
TGI-184G 25 31 28 34 230mm 610*490*510 0.16 177
TGI-184H 30 38 33 41 255mm 670*490*510 0.17 222
TGI-184J 34 43 37 47 285mm 670*490*510 0.17 235
TGI-224C 34 43 37 47 130mm 720*490*770 0.27 242
TGI-224D 40 50 44 55 160mm 720*490*770 0.27 265
TGI-224E 48 60 53 66 180mm 810*490*770 0.31 288
TGI-224F 58 73 64 80 240mm 810*490*770 0.31 320
TGI-224G 68 85 76 95 300mm 860*490*770 0.33 365
TGI-274C 80 100 88 110 165mm 810*580*850 0.40 390
TGI-274D 96 120 104 130 205mm 810*580*850 0.40 427
TGI-274ES 100 125 112 140 215mm 810*580*850 0.40 440
TGI-274E 112 140 124 155 230mm 930*580*850 0.46 490
TGI-274FS 120 150 132 165 250mm 930*580*850 0.46 510
TGI-274F 128 160 140 175 285mm 930*580*850 0.46 530
TGI-274G 146 183 160 200 335mm 980*580*850 0.49 593
TGI-274H 160 200 176 220 375mm 1020*585*850 0.51 625
TGI-274J 180 225 200 250 410mm 1110*585*850 0.55 660
TGI-274K 200 250 220 275 450mm 1110*585*850 0.55 680
TGI-314C 200 250 220 275 275mm 1150*680*930 0.73 851
TGI-314D 240 300 264 330 340mm 1150*680*930 0.73 931
TGI-314ES 260 325 288 360 410mm 1150*680*930 0.73 1022
TGI-314E 280 350 308 385 370mm 1150*680*930 0.73 950
TGI-314FS 304 380 336 420 500mm 1220*690*950 0.80 1150
TGI-314F 320 400 352 440 450mm 1220*690*950 0.80 1150
TGI-354C 360 450 400 500 350mm 1320*750*1050 1.04 1355
TGI-354D 400 500 440 550 430mm 1370*780*1050 1.13 1380
TGI-354E 488 610 536 670 500mm 1370*780*1050 1.13 1490
TGI-354FS 500 625 560 700 440mm 1370*780*1050 1.13 1550
TGI-354F 536 670 600 750 575mm 1370*780*1050 1.13 1640
TGI-404B 600 750 660 825 355mm 1750*920*1360 2.19 1920
TGI-404C 640 800 704 880 380mm 1750*920*1360 2.19 2015
TGI-404D 728 910 800 1000 410mm 1750*920*1360 2.19 2102
TGI-404E 800 1000 880 1100 470mm 1750*920*1360 2.19 2227
TGI-404F 900 1125 1000 1250 560mm 1750*920*1360 2.19 2452
TGI-404G 1000 1250 1100 1375 675mm 1780*920*1360 2.23 2820
TGI-454B 1080 1350 1200 1500 465mm 1940*1050*1540 3.14 2900
TGI-454C 1264 1580 1400 1750 550mm 1940*1050*1540 3.14 3091
TGI-454D 1400 1750 1540 1925 620mm 2160*1050*1540 3.50 3391
TGI-454E 1520 1900 1680 2100 700mm 2160*1050*1540 3.50 3629
TGI-454F 1664 2080 1840 2300 770mm 2160*1050*1540 3.50 3913
TGI-454G 1800 2250 2000 2500 820mm 2160*1050*1540 3.50 4127



























































15kVA 18kVA 20kVA Brushless Synchronous Alternator 22kVA Brushless Dynamo For Genset Applications 1

Applications:

The TECGEN Brushless Alternator is an ideal choice for generating reliable and efficient power. The TGI Series produces AC synchronous power with 100% copper winding and is available in both single and double bearing models. With a minimum order quantity of one and a competitive price, it is the perfect solution for a variety of applications. It is certified by ISO, CE, SASO, and SONCAP, and is safely and securely packaged with either plastic film or polywooden packaging. Delivery is available within 10 working days, and payment can be made via T/T or L/C. We are confident in our ability to supply up to 10,000 units per month. Our brushless dynamo provides a reliable and cost-effective solution for your AC alternator needs.

Customization:

TECGEN Brushless Alternator

TECGEN Brushless Alternator is a 100% Copper Alternator with a brand name of TECGEN and model number TGI series. It is certified with ISO / CE / SASO / SONCAP and is available in a minimum order of 1 SET. The price is negotiable and is delivered within 10 working days upon payment. The packaging is either done in a plastic film package or a polywooden package. The frequency is available in either 50Hz or 60Hz and the speed is available in either 1500RPM or 1800RPM. It is a brushless AC synchronous alternator and has a supply ability of 10000 units per month.



Packing and Shipping:

Packaging and Shipping for Other Generators:

  • Each generator is securely packaged in a corrugated cardboard box.
  • The boxes are then loaded onto a pallet and shrink-wrapped using a high-quality plastic film.
  • The pallet is then placed on a truck and secured with straps.
  • The truck is then driven to the destination, and the pallet is unloaded for delivery.


FAQ:

Q1: What is the brand name of Other Generators?

A1: The brand name is TECGEN Brushless Alternator.

Q2: What is the model number of Other Generators?

A2: The model number is TGI series.

Q3: Where is Other Generators from?

A3: Other Generators is from China.

Q4: What certifications does Other Generators have?

A4: Other Generators has ISO / CE / SASO / SONCAP certifications.

Q5: What is the minimum order quantity of Other Generators?

A5: The minimum order quantity of Other Generators is 1 SET.
