Silent Type Generator 50kW Silent Dg Set For Home Emergency Back-up Power
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Silent Type Generator | Prime Power | 50kW / 63kVA |
|---|---|---|---|
| Standby Power | 55kW / 69kVA | Output Type | AC 3 Phase |
| Frequency | 50Hz | Current | 95.7A |
| Power Factor | PF. 0.8 | Engine | Yangdong YD4EZLD |
| Highlight | 50kW silent type generator,50kW Silent Dg Set |
||
Product Description
Silent type generator 50kW silent dg set for home emergency back-up power
Product Description for Silent Type Generator
Key Features:
- Ultra-quiet operation for noise-sensitive environments.
- Versatile voltage options to meet diverse power needs.
- High-quality construction for long-term reliability.
Standard Features:
- Intelligent controller for smooth operation and easy monitoring.
- Efficient cooling system for optimal engine performance.
- Modular design for simplified maintenance.
50kW Silent Type Generator General Specifications:
| Silent Type Generator Technical Datasheets | ||||||
| Genset model | TG69YDS | |||||
| Genset Type | Silent | |||||
| Rated Voltage | 440V//415V/400V/380V/230V/220V/110V | |||||
| Frequency | 50Hz | |||||
| Speed | 1500rpm | |||||
| Output Type | AC Three Phase | |||||
| P.F(COS) | P.F. 0.8 | |||||
| Prime Output Current | 95.7A | |||||
| Prime Power | 50kW / 63kVA | |||||
| Standby Power | 55kW / 69kVA | |||||
| Diesel Engine | Brand | Yangdong | ||||
| Model | YD4EZLD | |||||
| AC Alternator | Brand | Tecgen Power | ||||
| Model | TGI224S50 | |||||
| Genset Controller | Brand | Smartgen | ||||
| Model | HGM6110N | |||||
| Genset Weight | 1300kgs | |||||
| Genset Dimensions | L2350 * W 1150 * 1350 | |||||
| Fuel Tank Capacity | 130L | |||||
| Yangdong Diesel Engine Data | ||||||
| Brand | Yangdong | |||||
| Engine Model | YD4EZLD | |||||
| Number of Cylinders | 4 Cylinder in Line | |||||
| Cycle | 4-troke | |||||
| Aspiration | Turbocharged & Intercooled | |||||
| Displacement | 4.1L | |||||
| Compression ratio | N.A | |||||
| Bore×Stroke | 105*118mm | |||||
| Speed | 1500rpm | |||||
| Prime Power | 63kW | |||||
| Standby Power | 69kW | |||||
| Speed Governor | Electrical | |||||
| Cooling System | Forced water cooling cycle | |||||
| Starting system | DC Motor | |||||
| Fuel Consumption at 100% Load | 207g/kwh@1500rpm | |||||
| AC Alternator Data | ||||||
| Brand | Tecgen Power | |||||
| Model | TGI224S50 | |||||
| Frequency/speed | 50HZ/1500RPM | |||||
| Rate Output | 63kVA | |||||
| No. of Phase | 3 Phase, 4 Wire | |||||
| Exciter type | Single bearing, Brushless, Self-excited with AVR | |||||
| Power factor | 0.8 | |||||
| Insulation Grade | H | |||||
| Protection Grade | IP23 | |||||
| Working Condition | Below 1000m | |||||
| Bearing | Single | |||||
| Coupling | Direct | |||||
| Voltage adjust range | ≥5% | |||||
| Voltage regulation NL-FL | ≤±1% | |||||
| Genset Controller System | ||||||
| Controller System | Brand | Smargen | ||||
| Model | HGM6110N | |||||
| Functions | Auto Mains (Utility) Failure | |||||
| Static with auto. battery charger | ||||||
| Emergency stop push button | ||||||
| ATS & RS485 Connection | ||||||
| CAN Functions | ||||||
| Diesel Generator Set Output ranges & Brand Options | ||||||
| Prime Power (kW) | Diesel Engine | AC Alternator | Controller | Type | ||
| 8kW ~ 2400kW | Cummins / Perkins / Deutz / Weichai / Yuchai / SDEC / Mitsubishi / Doosan / Wudong / Baudouin |
Leroy Somer / Stamford / Mecc Alte / Tecgen
|
DEIF | Open/Silent | ||
| 7kW ~ 320kW | Yangdong / FAWDE / Quanchai / YTO | Tecgen | Smartgen | |||
| 11kW ~ 104kW | Beinei Aircooled | Tecgen | ||||
| 10kW ~ 300kW | Weifang Ricardo | Stamford | DEEPSEA | |||
| 6.8kW ~ 2000kW | Caterpillar | Caterpillar | Caterpillar | |||
| 6.8kW ~ 2000kW | FG Wilson | FG Wilson | FG Wilson | |||
| 17kW ~ 30kW | Isuzu | Mecc Alte | ComAp | |||
| 210kW ~ 818kW | VMAN | Tecgen | Tecegn | |||
| 6kW ~ 2000kW | Chinese Engines | Smartgen | ||||
Usage:
Ideal for home use, hospitals, data centers, hotels, and construction sites where reliable and silent power is essential.
Options:
- Customizable power ratings and specifications to suit your needs.
- Additional accessories like soundproof canopies and exhaust silencers available.
Warranty:
Backed by a comprehensive 18-month or 1500-hour warranty for peace of mind and long-term performance.
FAQ:
- Q: How silent is the Silent Type Generator?
A: Extremely silent, designed for minimal noise pollution. - Q: Can I use it for home use?
A: Absolutely, it's a perfect silent dg set for home.
With its silent operation and versatile voltage options, the Silent Type Generator is your ideal choice for reliable and noise-reduced power. Contact us now for more details and to place your order!
