Soundproof 16kVA back-up generator standby generator set powered by Yangdong engine
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Soundproof | Product | Yangdong Generator Set |
|---|---|---|---|
| Frequency | 60Hz / 1800rpm | Voltage | 208V |
| Output Type | 3 Phase, 4 Wire Or 12 Wire | Engine Model | YD480D |
| ATS | Built-in ATS / Wall Mounted Box | Prime Power | 13kW / 16kVA |
| Highlight | back-up Soundproof generator set,Yangdong engine Soundproof generator set,standby Soundproof generator set |
||
Product Description
Soundproof 16kVA back-up generator standby generator set powered by Yangdong engine
Product Description for Soundproof 16kVA Backup Generator
Elevate your power backup solutions with our Soundproof 16kVA Backup Generator. Designed for both commercial and industrial use, this Standby Generator Set offers unparalleled reliability and quiet operation.
Standard Features:
- 16kVA capacity, ideal for medium-sized applications
- Soundproof enclosure for minimal noise emission
- Yangdong YD480D diesel engine for efficient power delivery
- MEBAY DC52D controller for precise system monitoring
Key Features:
- Soundproof design ensures minimal disturbance in noise-sensitive environments
- Automatic Transfer Switch (ATS) for seamless transition from utility to backup power
- Long-lasting Varta battery for reliable engine startup
Soundproof 16kVA Back-up Generator Specifications:
| Soundproof 16kVA Back-up Generator Datasheet | ||||
| Yangdong Back-up Generator Set | Genset Type | Soundproof | ||
| Genset Model | TG18YDSD6 | |||
| Prime Output | 13kW / 16kVA | |||
| Max Output | 14kW / 18kVA | |||
| Engine model | YD480D | |||
| Alternator | TGI164S13 | |||
| Frequency | 60Hz | |||
| Speed | 1800rpm | |||
| Voltage | 208V | |||
| Output Type | 3 Phase, 4 Wire | |||
| Current | 44.4A | |||
| Controller | MEBAY DC52D | |||
| ATS | Built-in ATS / Wall mounted Box | |||
| Breaker | Aisikai / Delixi | |||
| Battery | Varta | |||
| Fuel Tank | 8 running Hours | |||
| Demission | L1900x900x1170mm | |||
| Weight | 600kgs | |||
| Yangdong Diesel Engine Generator set parameters | ||||
| Voltage setting range | ≥±10% | |||
| Steady state voltage regulation rate | ≤0.5% | |||
| Transient voltage deviation (100% sudden power reduction) | ≤+17% | |||
| Transient Voltage Deviation (40% Sudden Power) | ≤-6.5% | |||
| Voltage Stability Time (100% Sudden Power Reduction) | ≤2.8S | |||
| Voltage Stability Time (40% Sudden Power) | ≤2.5S | |||
| Frequency adjustment range | ≥±10%Adjustble | |||
| Frequency volatility | ≤±0.25% | |||
| Transient frequency deviation (100% sudden power reduction) | ≤+8% | |||
| Transient frequency deviation (40% sudden power) | ≤-5% | |||
| Frequency Recovery Time (100% Sudden Power Reduction) | ≤1.48S | |||
| Frequency recovery time (40% sudden power) | ≤1.35S | |||
| Yangdong Diesel Engine Parameters | ||||
| Yangdong Engine YD480D | Brand | YANGDONG CO., LTD | ||
| Model | YD480D | |||
| Prime power | 16kW | |||
| Combustion | Direct Injection | |||
| No. of Cylinders | 4 Cylinder | |||
| Aspiration | Natural Aspiration | |||
| Compression Ratio | 18: 1 | |||
| Speed | 1800rpm | |||
| Displacement | 1.809 | |||
| Bore* Storke | 80mm*90mm | |||
| governor | MECH or Electric | |||
| Start motor | DC 24V | |||
| Cooling Capacity | 5.5 | |||
| Cooling Type | Water cooling | |||
| FUEL CONSUMPTION | 250g/kW.h | |||
| AC Brushless Alternator Parameters | ||||
| Alternator TGI164S13 | Brand | Tecgen | ||
| Model | TGI164S13 | |||
| Rate Output | 13kW | |||
| Rate Speed | 1800rpm | |||
| Frequency | 60Hz | |||
| Altitude | ≤1000 | |||
| Alternator type | Single bearing, brushless type | |||
| Connection Type | 3 phase, 4 wire | |||
| Protection Grade | IP23 | |||
| Insulation Class | H | |||
| Voltage Regulation | AVR | |||
| Option brand | Stamford,Leroy Somer,Meccalte | |||
| Ricardo Genset Controller System | ||||
| Controller MEBAY DC52D | Brand | MEBAY | ||
| Model | DC52D | |||
| Working Voltage | DC8.0V to DC35.0V, continuous | |||
| Overall Dimensions (mm) | 233*38.5*173 | |||
| Functions | AMF/ATS | |||
| RS485 & CAN communication | ||||
| 9 Inlet & 7 Outlet | ||||
| PLC & BTN | ||||
| Protections | Under-speed | |||
| Over-speed | ||||
| Configurable crank connect | ||||
| Battery monitoring | ||||
| Charging alternator | ||||
| Pre-heat | ||||
| Coolant temperature | ||||
| Lube oil pressure | ||||
| Fuel level detection | ||||
| Fuel theft detection | ||||
| ECU communication failure | ||||
| ECU diagnostic lamp | ||||
| Option brand | DEEPSEA,Smartgen,ComAp | |||
| Optional accessories | ||||
| Engine | Alternator | Electrical system | ||
| Water Heater | Anti-condensation heater | Anti-condensation heater | ||
| Oil preheater | PMG | Unit control screen with three remote functions | ||
| Air starting motor | Parallel | ATS automatic load transfer screen | ||
| Heavy Air Filter for Desert | Generators of other temperature rise grades | Full-automatic parallel screen for multiple units | ||
| Heavy duty secondary muffler | RTD temperature sensor, 2 per phase | Remote control system separate from unit | ||
| Fuel system | Other | Cooling system | ||
| 12/24h Base tank | Super Silent Canopy | Split water tank | ||
| Oil - water separator | Static sound box generator set |
|
||
| Fully automatic oil supply system | Vehicle-mounted power generation vehicle | Heat exchanger and external circulation cooling tower | ||
| Integrated Fuel Tank | Towing generator set | Marine cooling system | ||
| Delivery Date of Diesel Generator Set | ||||
| Spot goods | QTY(Set) | 12 – 24 Sets | 24 – 120 Sets | |
| Delivery Time | 7-15 Days | 15 – 25 Days | ||
| Custom | Delivery Time | 20 Days | 20 – 30 Days | |
Usage:
Whether it's for hospitals, data centers, or factories, our Soundproof 16kVA Backup Generator provides peace of mind during power outages.
Advantages:
- Fast and reliable startup, ensuring minimum downtime
- Stable voltage and frequency output, protecting sensitive equipment
- Long runtime on a single tank, reducing maintenance frequency
Options:
Customize your generator with a choice of breakers from Aisikai or Delixi, and alternators from Stamford, Leroy Somer, or Meccalte.
FAQ:
- Q: How loud is the generator when it's running?
A: With its soundproof enclosure, the generator operates at minimal noise levels, making it suitable for any environment.
Trust our Soundproof 16kVA Backup Generator for your standby power needs. Get yours today and enjoy the benefits of reliable, quiet backup power.
