Chinese Diesel Engine Generator Yangdong Genset With Single Phase Three Phase Output

  • Chinese Diesel Engine Generator Yangdong Genset With Single Phase Three Phase Output
  • Chinese Diesel Engine Generator Yangdong Genset With Single Phase Three Phase Output
Place of Origin Fuzhou, China
Brand Name Tecgen Power
Certification CE / SASO / SONCAP / COC / PVOC
Model Number TGYD
Minimum Order Quantity 1 unit
Price Negotiation
Packaging Details Stretch film packaging
Delivery Time 15 Days
Payment Terms T/T, L/C
Supply Ability 200 Units Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Open, Silent, Super Silent, Trailer Type Engine Brand Yangdong
Frequency 50Hz / 60Hz Engine Cylinder 4 Cylinder Water Cooled
Alternator AC Brushless Type Option Equipments ATS, Water Heater, Integrated Fuel Tank
Controller DEIF / DEEPSEA / Smartgen / ComAp / Tengen Power Range 10kVA To 83kVA
Highlight

Chinese Diesel Engine Yangdong Genset

,

Three Phase Yangdong Genset

,

Single Phase Yangdong Genset
Leave a Message
Product Description

Chinese diesel engine generator Yangdong genset with single phase & three phase output



FUJIAN TECGEN POWER CO., LTD.



FUJIAN TECGEN POWER CO., LTD. stands as a highly specialized and seasoned manufacturer of diesel generators, brush and brushless alternators, and AC motors. With over 15 years of dedication in this field (since 2006), we are consistently committed to producing diesel generators, brush and brushless alternators, and AC motors of the highest quality, all at competitive prices.



Our comprehensive product range includes:



  1. Diesel Engines (Chinese Brands): Up to 1000kW
  2. Portable Gasoline Generators: 0.5kW, 1kW, 2.0kW, 2.5kW, 2.7kW, 5.0kW, 6.0kW, 10kW, 13kW.
  3. Portable Diesel Generators: 2.0kW, 3.0kW, 5.0kW, 6.0kW, 8kW, 10kW, 13kW, 15kW.
  4. Water-cooled diesel generators spanning from 6kVA to 3000kVA.
  5. Brush and brushless alternators ranging in power from 1kW to 800kW.



We proudly power our products with renowned engines from Cummins, Ricardo, Deutz, Perkins, FAWDE, Yangdong, ISUZU, Yanmar, SDEC, Weichai, Baudouin, and more.





Here's why you should choose us:

  1. Over 15 years of manufacturing expertise, dating back to 2007.
  2. Vast experience in handling OEM orders.
  3. State-of-the-art production equipment.
  4. A dedicated design team that can assist in customizing packaging solutions.
  5. Use of genuine materials and meticulous craftsmanship.





As a professional manufacturer specializing in engines and generators, we integrate development, production, and sales. Our factory is located in Fuan City, while our specialized office is situated in Fuzhou, one of the earliest coastal cities to open up.



We cordially invite all partners to join us in a distributorship collaboration.



Chinese Diesel Engine Generator Yangdong Genset With Single Phase Three Phase Output 0



Yangdong Diesel Engine Genset Power Ranges:



FEATURE
Power Range: 7-60 ( 9KVA-75KVA)
Model: Open Type / Silent Type/ Super Silent Type
Engine: YANGDONG
Speed: 1500/1800rpm
Alterantor: Stamford/Leroy Somer/Marathon/Mecc Alte/TG
IP & Insulation Class: IP22-23 & F/H
Frequency: 50/60Hz
Controller: Deepsea/Smartgen/DEIF/Comap/Mebay/DATAKOM/Others
ATS System: AISIKAI/Others

YANGDONG Series Diesel Genset
Diesel Generator Set Techinical Specification ( 50Hz )
Genset Model Genset
Prime Power		 Genset
Standby Power		 Engine Model Engine
Max Power		 Cylinders Governor Alternator Model Fuel Consumption Dimension (LxWxH) mm
KVA kW KVA kW 　 L/H Open Type Silent Type
TG10YD 9 7 10 8 YD380D 11 3L Mechanical TGI164S7 3.1 1300x550x1000 1700x850x1050
TG11YD 10 8 11 9 YD385D 13 3L Mechanical TGI164S8 3.6 1400x550x1000 1900x900x1120
TG15YD 14 11 15 12 YD480D 15 4L Mechanical TGI164S11 4.1 1400x550x1000 1900x900x1120
TG18YD 16 13 18 14 YND485D 19 4L Mechanical TGI164S13 4.9 1400x550x1000 2100x900x1120
TG21YD 19 15 21 17 YND490D 22 4L Mechanical TGI184S15 5.8 1600x650x1000 2100x900x1120
TG22YD 20 16 22 18 YSD490D 23 4L Mechanical TGI184S16 6.0 1600x650x1000 2100x900x1120
TG25YD 23 18 25 20 Y490D 26 4L Mechanical TGI184S18 6.9 1600x700x1100 2100x900x1180
TG28YD 25 20 28 22 Y495D 30 4L Mechanical TGI184S20 7.6 1600x700x1100 2100x900x1180
TG28YD 25 20 28 22 Y4100D 33 4L Mechanical TGI184S24 8.4 1700x700x1100 2280x900x1180
TG34YD 31 25 34 28 Y4102D 36 4L Mechanical TGI184S25 9.1 1700x750x1100 2280x900x1180
TG41YD 38 30 41 33 Y4105D 42 4L Mechanical TGI184S30 10 1750x750x1100 2200x950x1200
TG44YD 40 32 44 35 Y4102ZD 44 4L Mechanical TGI184S32 11 1850x750x1100 2250x1000x1250
TG52YD 48 38 52 42 Y4102ZLD 53 4L Mechanical TGI224S36 13 1850x750x1100 2250x1000x1250
TG55YD 50 40 55 44 Y4105ZLD 61 4L Electrical TGI224S40 14 1850x750x1100 2300x1000x1300
TG69YD 63 50 69 55 YD4EZLD 69 4L Electrical TGI224S50 16 1900x750x1100 2400x1000x1300
TG83YD 75 60 83 66 Y4110ZLD 88 4L Electrical TGI224S60 21 2000x900x1200 2500x1100x1300



Chinese Diesel Engine Generator Yangdong Genset With Single Phase Three Phase Output 1



Δ TESTING PARAMETERS


TECGEN POWER offers an extensive range of brand-new, premium-quality products.
Each unit undergoes rigorous factory testing before dispatch.



  1. Component malfunction detection
  2. Fuel tank pressure evaluation
  3. Bolt tightening torque assessment
  4. Paint coating thickness analysis
  5. Voltage endurance and insulation testing
  6. Noise level measurement
  7. Loading Test: Comprehensive testing at 25%, 50%, 75%, 100%, and 110% load to validate all control systems, alarms, and shutdown safeguards.





Δ ADDITIONAL OFFERINGS



  1. Weather-resistant enclosure / Sound-insulated canopy / Trailer-mounted units
  2. Engine / Alternator Pre-heaters
  3. Automatic load distribution & synchronization panel
  4. Built-in ATS (Automatic Start & Stop for Main Failure (AMF))
  5. Wall-mounted ATS Box or ATS Cabinet
  6. Extended 12/24-hour fuel tank
  7. Integrated Fuel Tank
  8. Power output sockets
  9. Fuel-Water Separator
  10. Remote Control capabilities





Warranty Terms:


yangdong Genset are warranted against material and workmanship defects for a duration of 18 months or 1500 operating hours, whichever occurs first, from the date of delivery to the end user. Exceptions apply to replaceable parts of diesel generators damaged due to improper human operation. The aforementioned warranty is further supported by the engine and alternator suppliers.
