Silent / Super Silent Type Diesel Power Generator Set Up To 2 Years Or 2000 Hours

Place of Origin China
Brand Name Tecgen Cummins Genset
Certification ISO / CE / SASO / CIQ
Model Number TG103CS
Minimum Order Quantity 1 SET
Price Negotiation
Packaging Details Plastic film package in container
Delivery Time 7 Working Days
Payment Terms T/T / L/C
Supply Ability 300 Units Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Noise Level As Low As 65 DB(A) Warranty Up To 2 Years Or 2000 Hours
Genset Type Silent / Super Silent Type Colors RAL Standard Colors Or Customed
Voltage 220/380V, 230/400V, 240/415V Fuel Tank Capacity Up To 10 Operation Hours
Options Weatherproof Enclosures, Auto Transfer Switches, Etc. Prime Genset Output 75kW / 94kVA
Leave a Message
Product Description



Silent / Super Silent Type Diesel Power Generator Set Up To 2 Years Or 2000 Hours

Product Description:

Cummins Diesel Generators are the perfect choice for reliable power. Featuring Cummins Marine Diesel Engines and Cummins Diesel Truck Engines, these generators offer prime genset output of up to 30kVA and a frequency of 50Hz, while keeping noise levels as low as 65 DB(A). In addition, they are available in a range of RAL standard colors or in custom colors. Providing superior performance, Cummins Diesel Generators are available in both silent and super silent types.



Features:

  • Product Name: Cummins Diesel Generators
  • Colors: RAL Standard Colors Or Customed
  • Options: Weatherproof Enclosures, Auto Transfer Switches, Etc.
  • Voltage: 220/380V, 230/400V, 240/415V
  • Engine Brand: Cummins
  • Warranty: Up To 2 Years Or 2000 Hours
  • Cummins Diesel Engine Parts
  • Cummins Diesel Truck Engines
  • Diesel Power Generator Set



Silent / Super Silent Type Diesel Power Generator Set Up To 2 Years Or 2000 Hours 0

Technical Parameters:

Technical Specification:
Generator Set Specification
Genset Model TG103C TG103CS
Open Silent
Frequency 50Hz
Voltage 400/230V
Phase 3
Rate Current 135.7A
Prime Power 75kW / 94kVA
Standby Power 83kW / 103kVA
Engine Model 4BTA3.9-G13
Alternator Model TGI274S75
Controller DSE7320
Weight & Dimensions
Length (mm) 2240 2700
Width (mm) 900 1020
Height (mm) 1400 1530
Weight (kgs) 1200 1850
Engine Specication
Brand Cummins
Engine Model 4BTA3.9-G13
Standby power (kw) 106
Injection Indirect
Aspiration Turbocharged and Intercooled
No. of cylinders 4
Bore of Stroke (mm) 102 x 120
Displacement (L) 3.9
Cooling water
Compression Ratio 17.3:1
Engine Oil capacity (L) 10
Coolant Capacity ( In radiator) 10
Governor Electric
Air Filter Dry Element
Fuel consumption at 50Hz
100% Load (L/h) 17.9
75% Load (L/h) 13.4
50% Load (L/h) 8.9
25% Load (L/h) 4.5
Alternator Specification
Brand Tecgen
Model TGI274S75
Rate Output (kVA) 94
Pole 4
Winding Connections Star
Insulation Class H
Enclosure IP23
Altitude (m) ≤1000
Voltage Regulator AVR
Steady State Voltage Regulator 1%
Bearing Single
Controller System
Brand Deepsea
Model DSE7320
Functions Control with AMF module
Static with auto. battery charger
Emergency stop push button
ATS Connection
OPTIONAL EQUIPMENTS
ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts

Silent / Super Silent Type Diesel Power Generator Set Up To 2 Years Or 2000 Hours 1

Applications:

Tecgen Cummins Genset is a brand of Cummins diesel generators that provide a wide range of applications and scenarios. It is certified by ISO, CE, SASO and CIQ, and has a minimum order quantity of 1 set, while the price is negotiable. The engine brand is Cummins, and the noise level can be as low as 65 dB(A). It is available in silent and super silent type, and is packaged with plastic film package in container for delivery. The voltage options are 220/380V, 230/400V, 240/415V, and it comes with up to 2 years or 2000 hours warranty. Tecgen Cummins Genset is also available in terms of supply ability of up to 300 Units per month, with payment terms of T/T or L/C. It is popular for its Cummins diesel generator parts, Cummins marine diesel engines, Cummins diesel engine parts, Cummins diesel generator and Cummins diesel generators.



Support and Services:

Cummins Diesel Generators Technical Support and Service

Cummins Diesel Generators provide customers with reliable technical support and service. Cummins provides customers with a comprehensive suite of solutions that are designed to meet their needs, from onsite technical support to online resources and remote support.

Our technical support team is available 24/7 to help customers troubleshoot and repair their Cummins Diesel Generators. We provide our customers with detailed instructions on how to properly use their equipment, as well as diagnostic tools and repair information.

We also offer preventive maintenance services to help customers ensure their Cummins Diesel Generators are always performing at their peak. Our team of certified technicians can perform a variety of preventative maintenance services, including filter changes, oil changes, and system checks.

We offer extended warranties on all Cummins Diesel Generators, so customers can enjoy peace of mind knowing that their equipment is backed by a reliable service and support team. All of our extended warranties include access to our online resources, technical support, and repair services.



Packing and Shipping:

Cummins Diesel Generators come with standard packaging and shipping to ensure they arrive safely and in perfect condition. The packaging includes a durable plastic shipping container with an internal foam lining and a cardboard box for extra protection. The packaging also includes a fitting that is compatible with any standard shipping system.

The shipping process typically takes 1-2 weeks, depending on the size of the generator and the location of delivery. For international orders, additional paperwork is required that can extend the delivery time. All orders are tracked and monitored throughout the entire shipping process to ensure that the generator arrives on time and in perfect condition.

Silent / Super Silent Type Diesel Power Generator Set Up To 2 Years Or 2000 Hours 2Silent / Super Silent Type Diesel Power Generator Set Up To 2 Years Or 2000 Hours 3

FAQ:

Q&A about Tecgen Cummins Genset
Q1: What is the model number of Tecgen Cummins Genset?
A1: The model number is TGC.
Q2: Where is the Tecgen Cummins Genset made?
A2: It is made in China.
Q3: What certifications does Tecgen Cummins Genset have?
A3: It has ISO / CE / SASO / CIQ certification.
Q4: What is the minimum order quantity?
A4: The minimum order quantity is 1 SET.
Q5: How long will it take to deliver the Tecgen Cummins Genset?
A5: It will take 7 working days to deliver the product.
