600kVA Silent Electric Generators 50Hz Silent Genset With AMF25 AMF Function Controller
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Genset Type | Silent DG Genset | Rate Output Genset | 480kW / 600kVA |
|---|---|---|---|
| Frequency | 50Hz / 1500rpm | Phase | 3 Phase / 4 Wire |
| Cooling System | Water-cooled | Equipment Options | ATS, Water Heater, Engine Heater, PMG, Remote Control |
| Colors | RAL Standard Or Customed Colors | Noise Level | 70dB(A)@7m |
| Highlight | 600kVA Silent Electric Generators,Silent Electric Generators 50Hz,480kW 3 phase silent generator |
||
Product Description
600kVA silent electric generators 50Hz silent genset with AMF25 AMF function Controller
Product Description:
Silent Power Generators are designed to provide reliable, noiseless emergency power in critical situations. Our generators offer a frequency of 50Hz / 1500rpm with a rate output of 480kW / 600kVA and provide a range of equipment options, including ATS, Water Heater, Engine Heater, PMG, and Remote Control. They are available in either RAL Standard or Customed colors and offer a noise level of 70dB(A)@7m. Silent Power Generators are the ideal solution for any quiet DG generator needs, as they offer reliable performance and maximum efficiency in emergency situations.Features:
- Product Name: Silent Power Generators
- Rate Output Genset: 480kW / 600kVA
- Standby Output Genset: 520kW / 650kVA
- Alternator Brand: Leroy Somer / Stamford / Tecgen
- Noise Level: 70dB(A)@7m
- Phase: 3 Phase / 4 Wire
- Colors: RAL Standard Or Customed Colors
- Special Feature: Soundproof DG Genset, Super Silent Genset, Silent Electric Generators
Technical Parameters:
| Technical Specification: | ||
| Silent 600kVA Diesel Generator Specification | ||
| Genset Model | TG650C | TG650CS |
| Open | Silent | |
| Frequency | 50Hz | |
| Voltage | 400/230V | |
| Phase | 3 | |
| Rate Current | 866.1A | |
| Prime Power | 480kW / 600kVA | |
| Standby Power | 520kW / 650kVA | |
| Engine Model | KTA19-G8 | |
| Alternator Model | ECO40-1.5L/4A | |
| Controller | ComAP IL-AMF 25 | |
| Weight & Dimensions | ||
| Length (mm) | 3650 | 4510 |
| width (mm) | 1500 | 1880 |
| Height (mm) | 2200 | 2350 |
| Weight (kgs) | 4500 | 5650 |
| Engine Specification | ||
| Brand | CCEC Cummins | |
| Engine Model | KTA19-G8 | |
| Standby power (kW) | 575 | |
| Injection | Indirect | |
| Aspiration | Turbocharged and Charge Air Cooled | |
| No. of cylinders | 6 | |
| Bore of Stroke (mm) | 159 x 159 | |
| Displacement (L) | 18.9 | |
| Cooling | water | |
| Compression Ratio | 13.5:1 | |
| Engine Oil capacity (L) | 66 | |
| Coolant Capacity ( In radiator) | 66 | |
| Governor | Electric | |
| Air Filter | Dry Element | |
| Fuel consumption | at 50Hz | |
| 100% Load (L/h) | 119.4 | |
| 75% Load (L/h) | 89.6 | |
| 50% Load (L/h) | 59.7 | |
| 25% Load (L/h) | 29.9 | |
| Alternator Specification | ||
| Brand | Mecc Alte | |
| Model | ECO40-1.5L/4A | |
| Rate Output (kVA) | 600 | |
| Pole | 4 | |
| Winding Connections | Star | |
| Insulation Class | H | |
| Enclosure | IP23 | |
| Altitude (m) | ≤1000 | |
| Voltage Regulator | AVR | |
| Steady State Voltage Regulator | 1% | |
| Bearing | Single | |
| Controller System | ||
| Brand | ComAp | |
| Model | IL-AMF 25 | |
| Functions | Control with AMF module | |
| Static with auto. battery charger, overcurrent | ||
| Emergency stop push button | ||
| RS232, CAN | ||
| OPTIONAL EQUIPMENTS | ||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | ||
Applications:
Silent DG Genset TG650CS is a brand-name, industrial use genset manufactured in China. It is certified by ISO / CE / SASO / CIQ and is supplied with a minimum order quantity of 1 unit. With its super silent operation, Silent DG Genset TGR can provide a rate output of 600kVA at a frequency of 50Hz/1500rpm, making it the ideal choice for many industrial applications. The cooling system is water-cooled and the alternator brand available are Leroy Somer / Stamford / Tecgen. This reliable genset is also easy to maintain and has a delivery time of 15 working days. Silent DG Genset TG650CS is truly a versatile generator that can be used in a variety of places, such as factories, hospitals, schools, offices etc. Its price is negotiable, with packaging details of Plastic film package in container, and supply ability of 300 units per month. Finally, payment terms are available in T/T or L/C.
Customization:
Silent DG Genset - Emergency Generator, Soundproof DG Genset, Generator Set Quiet
Brand Name: Silent DG Genset
Model Number: TG650CS
Place of Origin: CHINA
Certification: ISO / CE / SASO / CIQ
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Plastic film package in container
Delivery Time: 15 Working Days
Payment Terms: T/T or L/C
Supply Ability: 300 Units Per Month
Genset Type: Silent DG Genset
Equipment Options: ATS, Water Heater, Engine Heater, PMG, Remote Control
Frequency: 50Hz / 1500rpm
Engine Brand: Cummins
Alternator Brand: Leroy Somer / Stamford / Tecgen
The Silent DG Genset is designed for emergency situations and is perfect for those who need a generator set that runs quietly and reliably. This soundproof DG genset is perfect for use in both residential and commercial settings. It features a Cummins engine and a Leroy Somer / Stamford / Tecgen alternator for reliable power in any situation. It also includes a variety of equipment options, such as ATS, water heater, engine heater, PMG, and remote control. With a frequency of 50Hz / 1500rpm, this generator set provides the perfect amount of power for any situation. In addition, its minimum order quantity is only 1 unit and it has a delivery time of 15 working days.
If you're looking for a reliable, quiet generator set for emergency situations, the Silent DG Genset is the perfect choice. With its top-of-the-line Cummins engine and variety of equipment options, you can be sure that you are getting the best generator set available. So don't wait - get your Silent DG Genset today!
Packing and Shipping:
Silent Power Generators Packaging and Shipping:
Silent Power Generators will be shipped in a securely sealed box with a protective wrapping to ensure a safe journey. The box must be handled with care to avoid any damage in transit. Upon arrival, the customer should immediately inspect the box for any damages and make sure the product is in proper working condition.
The package will include the Silent Power Generator, the instruction manual, and any necessary accessories. The instructions must be followed closely to ensure proper installation and use. Additionally, the customer must be aware of any local laws and regulations that may apply before using the product.
FAQ:
- Q: What is the brand name of Silent DG Genset?
A: The brand name of Silent DG Genset is Silent DG Genset. - Q: What is the model number of Silent DG Genset?
A: The model number of Silent DG Genset is TG650CS. - Q: Where is Silent DG Genset from?
A: Silent DG Genset is from Fuzhou, CHINA. - Q: What kind of certifications does Silent DG Genset have?
A: Silent DG Genset has ISO / CE / SASO / CIQ certifications. - Q: What is the minimum order quantity of Silent DG Genset?
A: The minimum order quantity of Silent DG Genset is 1 Unit.
