Automatic Control Yuchai Diesel Generator 20kW Open Type Diesel Generator With Electric Starting System 1500rpm
| Place of Origin | Fuzhou, China |
|---|---|
| Brand Name | Tecgen Yuchai DG Set |
| Certification | ISO / CE / SASO / CIQ / CO |
| Model Number | TG25YC |
| Minimum Order Quantity | 1 SET |
| Price | Negotiation |
| Packaging Details | Plastic film package or Polywooden Package |
| Delivery Time | 9 Working Days |
| Payment Terms | T/T / L/C |
| Supply Ability | 400 Units Per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Control System | Automatic/Manual | Frequency | 50Hz |
|---|---|---|---|
| Standby Power | 20KW / 25kVA | Trademark | TECGEN POWER |
| Conditions Of Use | Standby, Backup, Emergency Use | Warranty | 1500 Running Hours |
| Engine Brand | Yuchai Engine | Starting System | Electric/Manual |
| Highlight | Automatic Control Yuchai Diesel Generator,Yuchai Diesel Generator 20kW,25kVA open type diesel generator |
||
Product Description
Automatic Control 20kW Open type diesel generator with Electric Starting System 1500rpm
Product Description:
Yuchai Diesel Generator is an advanced diesel power generator set manufactured by TECGEN POWER in China. Featuring excellent performance and stability, it is capable of providing reliable power for standby, backup and emergency use. With a warranty of 1500 running hours, the generator comes with an automatic or manual control system, and can operate at a frequency of 50Hz. This high-quality diesel engine generator set offers superior performance and reliability. It is one of the most popular choices among customers for its outstanding performance, cost-effectiveness and reliable power.
Features:
- Product Name: Yuchai Diesel Generator
- Trademark: TECGEN POWER
- Starting System: Electric/Manual
- Control System: Automatic/Manual
- Standby Power: 20KW / 25kVA
- Warranty: 1500 Running Hours
- China Diesel Generator
- DG Power Generator
- China Diesel Generator Set
Technical Parameters:
| Technical Specification: | ||
| Yuchai 18kW DGGenerator Set Specification | ||
| Genset Model | TG25YC | TG25YCS |
| Open | Silent | |
| Frequency | 50Hz | |
| Voltage | 415/240V | |
| Phase | 3 | |
| Rate Current | 32.0A | |
| Prime Power | 18kW / 23kVA | |
| Standby Power | 20kW / 25kVA | |
| Engine Model | Yuchai YCD4V12D-35 | |
| Alternator Model | TGI184S18 | |
| Controller | Mebay DC52D | |
| Weight & Dimensions | ||
| Length (mm) | 1780 | 2200 |
| width (mm) | 840 | 980 |
| Height (mm) | 1360 | 1460 |
| Weight (kgs) | 800 | 1150 |
| Engine Specification | ||
| Brand | Yuchai | |
| Engine Model | YCD4V12D-35 | |
| Prime power (kw) | 23 | |
| Injection | Indirect | |
| Aspiration | Turocharged | |
| No. of cylinders | 4 | |
| Bore of Stroke (mm) | 89 x 100 | |
| Displacement (L) | 2 | |
| Cooling | water | |
| Compression Ratio | 17.3:1 | |
| Engine Oil capacity (L) | 4.3 | |
| Coolant Capacity ( In radiator) | 4.3 | |
| Governor | Electric | |
| Air Filter | Dry Element | |
| Fuel consumption | at 50Hz | |
| 100% Load (L/h) | 4.3 | |
| 75% Load (L/h) | 3.3 | |
| 50% Load (L/h) | 2.2 | |
| 25% Load (L/h) | 1.1 | |
| Alternator Specification | ||
| Brand | Tecgen | |
| Model | TGI184S18 | |
| Rate Output (kVA) | 23 | |
| Pole | 4 | |
| Winding Connections | Star | |
| Insulation Class | H | |
| Enclosure | IP23 | |
| Altitude (m) | ≤1000 | |
| Voltage Regulator | AVR | |
| Steady State Voltage Regulator | 1% | |
| Bearing | Single | |
| Controller System | ||
| Brand | Mebay | |
| Model | DC52D | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| ATS Connection | ||
| OPTIONAL EQUIPMENTS | ||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | ||
Applications:
The Tecgen Yuchai DG Set is a Diesel Power Generator Set with a Model Number of TG25YC. It is made in Fuzhou, China, and certified by ISO / CE / SASO / CIQ / CO. It has a minimum order quantity of 1 SET, and its price is subject to negotiation. It is packaged in either plastic film package or Polywooden Package, and can be delivered within 9 working days. Payment can be done through T/T / L/C. Its supply ability is 400 Units Per Month. It has both electric and manual starting system, and its trademark is TECGEN POWER. It also has a warranty of 1500 Running Hours. It has an Output Type of AC Three Phase, and it is powered by a Yuchai Engine.
The Tecgen Yuchai DG Set is an ideal solution for those looking for an Electric Diesel Generators or DG Power Generator. It is reliable and efficient, and is an excellent choice for anyone looking for a high-performance Yuchai Diesel Generator.
Customization:
Yuchai Diesel Generator
Brand Name: Tecgen Yuchai DG Set
Model Number: TG25YC
Place of Origin: Fuzhou, China
Certification: ISO / CE / SASO / CIQ / CO
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Plastic film package or Polywooden Package
Delivery Time: 9 Working Days
Payment Terms: T/T / L/C
Supply Ability: 400 Units Per Month
Output Type: AC Three Phase
Control System: Automatic/Manual
Starting System: Electric/Manual
Trademark: TECGEN POWER
Frequency: 50Hz
Industrial Diesel Generators, DG Power Generator, Industrial Diesel Generators
Yuchai Diesel Generator is a trusted brand for industrial diesel generators. It is certified with ISO / CE / SASO / CIQ / CO and has a minimum order quantity of 1 set. Yuchai Diesel Generator offers a reliable and efficient control system with automatic/manual control, electric/manual starting system and AC three phase output. The product is packed with plastic film package or polywooden package and is available for delivery in just 9 working days. Payment terms are flexible with T/T / L/C and supply ability is 400 units per month. Get the best price for your Yuchai Diesel Generator by negotiating with the supplier.
Packing and Shipping:
Yuchai Diesel Generator packaging and shipping:
Yuchai diesel generators are packaged using strong, durable wooden crates with metal bands and plastic wrapping. Generators are shipped via reliable freight carriers and arrive on time and in perfect condition.
FAQ:
Q&A
Q1: What is the brand name of the Yuchai Diesel Generator?
A1: The brand name of the Yuchai Diesel Generator is Tecgen Yuchai DG Set.
Q2: What is the model number of the Yuchai Diesel Generator?
A2: The model number of the Yuchai Diesel Generator is TG25YC.
Q3: Where is the Yuchai Diesel Generator produced?
A3: The Yuchai Diesel Generator is produced in Fuzhou, China.
Q4: What kind of certifications does the Yuchai Diesel Generator have?
A4: The Yuchai Diesel Generator has ISO / CE / SASO / CIQ / CO certifications.
Q5: How many units of the Yuchai Diesel Generator can you supply per month?
A5: We can supply 400 units of the Yuchai Diesel Generator per month.
