50Hz Diesel Generator Set
| Place of Origin | China |
|---|---|
| Brand Name | Yangdong generator |
| Certification | ISO / CE / SASO / CIQ / CO |
| Model Number | TG21YDS & TG22YDS |
| Minimum Order Quantity | 1 Uint |
| Price | Negotiation |
| Packaging Details | Plastic film package or Polywooden Package |
| Delivery Time | 7 working days after received deposit |
| Payment Terms | T/T / L/C |
| Supply Ability | 400 Units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Starting System | Manual | Control System | Automatic/Manual |
|---|---|---|---|
| Rated Frequency | 50Hz | Rate Power | 19kVA & 20kVA |
| Brand | Yangdong | Rated Voltage | 220, 230, 240, 380, 400, 415V |
| Options | ATS, Super Silent Type, Trailer Mounted | Cooling System | Water Cooled |
| Highlight | 50Hz diesel generator set,20kVA diesel generator set,19kVA dg set generator |
||
Product Description
50Hz China diesel engine silent diesel generator set silent canopy noise levels with 68dAB(A)
Product Description:
Yangdong Genset is a reliable and high-performance diesel genset for residential and commercial use. It is powered by a strong and efficient Yangdong engine and equipped with a reliable alternator that is capable of producing 19kVA & 20kVA of prime power. The generator set is designed with a manual starting system, rated frequency of 50Hz, water-cooled cooling system and automatic/manual control system.
Yangdong Genset is a silent generator set that offers superior performance and low noise levels. Its advanced design and cutting-edge technology ensure reliable power supply and long-term operation. It is ideal for residential and commercial use, and can be used for a variety of applications, such as lighting, powering tools, and providing backup power.
Yangdong Genset is the perfect choice for those who are looking for a reliable and cost-effective diesel generator set. It offers superior performance and low noise levels, and is the ideal solution for residential and commercial applications.
Features:
- Product Name: Yangdong Genset
- Options: ATS, Super Silent Type, Trailer Mounted
- Prime Power: 19kVA & 20kVA (15kW & 16kW)
- Rated Frequency: 50Hz
- Cooling System: Water Cooled
- Rated Voltage: 220, 230, 240, 380, 400, 415V
- Genset Diesel: Yes
- Silent Diesel Generator Set: Yes
- Genset Diesel Engine: Yes
- Water Cooled Genset: Yes
Technical Parameters:
| Technical Specification: | ||||
| Silent DG Generator Set 19kVA & 20kVA Specification | ||||
| Genset Model | TG21YD | TG21YDS | TG22YD | TG22YDS |
| Open | Silent | Open | Silent | |
| Frequency | 50Hz | |||
| Voltage | 415/240V | |||
| Phase | 3 | |||
| Rate Current (A) | 25.6 | 29.2 | ||
| Prime Power | 15kW / 19kVA | 16kW / 20kVA | ||
| Standby Power | 17kW / 21kVA | 18kW / 22kVA | ||
| Engine Model | YND490D | YSD490D | ||
| Alternator Model | TGI184S15 | TGI184S16 | ||
| Controller | Mebay DC52D | |||
| Fuel Tank Capacity | 50L | 50L | ||
| Weight And Dimensions | ||||
| Length (mm) | 1200 | 1900 | 1200 | 1900 |
| Width (mm) | 750 | 850 | 750 | 850 |
| Height (mm) | 950 | 1100 | 950 | 1100 |
| Weight (kgs) | 700 | 950 | 750 | 1000 |
| Engine Specification | ||||
| Engine Model | YND490D | YSD490D | ||
| Prime (kW) | 17 | 21 | ||
| Injection | Indirect | Indirect | ||
| Aspiration | Naturally Aspirated | Naturally Aspirated | ||
| No. of cylinders | 4 | 4 | ||
| Bore of Stroke (mm) | 85 x 95 | 90 x 100 | ||
| Displacement (L) | 2.156 | 2.54 | ||
| Cooling | water | water | ||
| Compression Ratio | 18:1 | 18:1 | ||
| Engine Oil capacity (L) | 5.3 | 5.3 | ||
| Coolant Capacity ( In radiator) | 5.3 | 5.3 | ||
| Governor | Mechanical | Mechanical | ||
| Air Filter | Dry Element | Dry Element | ||
| Fuel consumption | at 50Hz | at 50Hz | ||
| 100% Load (L/h) | 4.4 | 4.7 | ||
| 75% Load (L/h) | 3.3 | 3.5 | ||
| 50% Load (L/h) | 2.2 | 2.4 | ||
| 25% Load (L/h) | 1.1 | 1.2 | ||
| Alternator Specification | ||||
| Brand | Tecgen | Tecgen | ||
| Model | TGI184S15 | TGI184S16 | ||
| Rate Output (kW) | 15 | 16 | ||
| Pole | 4 | |||
| Winding Connections | Star | |||
| Insulation Class | H | |||
| Enclosure | IP23 | |||
| Altitude (m) | ≤1000 | |||
| Voltage Regulator | AVR | |||
| Steady State Voltage Regulator | 1% | |||
| Bearing | single | |||
| Controller System | ||||
| Brand | Mebay | |||
| Model | DC52D | |||
| Functions | Control with AMF module | |||
| Static with auto. battery charger | ||||
| Emergency stop push button | ||||
| ATS Connection | ||||
| OPTIONAL EQUIPMENTS | ||||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | ||||
Applications:
Yangdong Generator Set is a power generator set and genset diesel with brand name Yangdong. This model number TG21YDS & TG22YDS is certified by ISO/CE/SASO/CIQ/CO, with a minimum order quantity of 1 unit and price can be negotiated. It is packaged in plastic film package or polywooden package and delivery time is 7 working days after received deposit. The payment terms are T/T/L/C and the supply ability is up to 400 units per month. This Yangdong diesel generator is equipped with manual starting system and rated voltage of 220, 230, 240, 380, 400, 415V. It also offers optional features such as ATS, super silent type, trailer mounted and power range from 9-83kVA.
Customization:
Yangdong Generator Set
Yangdong generator set is a silent generator set with a brand name of Yangdong and model number of TG21YDS & TG22YDS. It is certified with ISO / CE / SASO / CIQ / CO and its minimum order quantity is 1 unit. The price is negotiable and the packaging details are either plastic film package or polywooden package. The delivery time is 7 working days after receiving the deposit, and the payment terms are T/T or L/C. The supply ability is 400 units per month and its rated voltage is 220, 230, 240, 380, 400, 415V. It has a manual starting system and an automatic/manual control system. Its rated frequency is 50Hz.
Our Yangdong generator set is the perfect choice for those who need a silent generator set with reliable quality. It is designed to provide reliable power and efficient performance with its excellent features. So, if you're looking for a reliable and efficient silent generator set, then Yangdong generator set is your best choice.
Packing and Shipping:
Yangdong Genset Packaging and Shipping
Yangdong Genset products are packaged and shipped in strong and durable boxes to ensure the integrity of the generator and its components. Each shipment is insured for its full value. The box is marked with the type of product, its weight, and dimensions for easy handling and tracking.
Each box is sealed with a tamper-proof seal to prove that the contents have not been tampered with during shipping. In addition, all boxes are labeled with the proper shipping and handling instructions, including the destination address. All orders are shipped with tracking numbers to ensure the product is delivered on time.
We take great care in ensuring that all of our Yangdong Genset products are packaged and shipped with the utmost care and efficiency. We also offer expedited shipping options for customers who need their product quickly.
FAQ:
Yangdong Generator FAQ
- Q: What is the brand name of the generator?
A: The brand name of the generator is Yangdong. - Q: What is the model number of the generator?
A: The model number of the generator is TG21YDS & TG22YDS. - Q: Where is the generator made?
A: The generator is made in China. - Q: What certifications does the generator have?
A: The generator has ISO / CE / SASO / CIQ / CO certifications. - Q: What is the minimum order quantity?
A: The minimum order quantity is 1 unit. - Q: How is the generator packaged?
A: The generator is packaged in plastic film package or polywooden package. - Q: How long does it take for the generator to be delivered?
A: The generator will be delivered within 7 working days after receiving the deposit. - Q: What payment terms are accepted?
A: We accept payment terms T/T or L/C. - Q: How many units can be supplied per month?
A: We can supply up to 400 units per month.
