Diesel 150 Kva Cummins Generator 60HZ 220V 240V 440V 460V
| Place of Origin | China |
|---|---|
| Brand Name | Tecgen Cummins Genset |
| Certification | ISO / CE / SASO / CIQ |
| Model Number | TGC |
| Minimum Order Quantity | 1 SET |
| Price | Negotiation |
| Packaging Details | Plywood case / Foam and PE film package |
| Delivery Time | 15 Working Days |
| Payment Terms | T/T / L/C |
| Supply Ability | 300 Units Per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Genset Type | Silent / Super Silent Type | Frequency | 60Hz |
|---|---|---|---|
| Power Output | 25kVA--2500kVA | Alternator Brand | Stamford / Leroy Somer / Tecgen |
| Warranty | 18 Months | Options | Auto Transfer Switch(ATS) |
| Voltage | 220V, 240V, 440V 460V And Other Voltage Is Optional | Engine Brand | Cummins |
| Highlight | Diesel 150 kva cummins generator,150 kva cummins generator 60HZ,460V cummins 150 kva |
||
Product Description
150kVA Cummins Diesel Generators 60HZ 220V 240V 440V 460V And Other Voltage Is Optional
Product Description:
Cummins Diesel Generators are world-leading diesel engine powered generators, designed and manufactured by Cummins, the global leader in diesel engine technology. The generators are available in a range of power outputs from 25 kVA to a maximum of 2500 kVA, and can be powered by a range of Cummins diesel truck engines and marine diesel engines. The generators can be configured to various voltages, including 220V, 240V, 440V and 460V, and can also be customized with additional options such as an Auto Transfer Switch (ATS). Cummins Diesel Generators are designed to deliver reliable, efficient and cost-effective power solutions. Cummins offers a full range of genuine Cummins diesel generator parts to ensure maximum performance, safety and longevity.
Features:
- Product Name: Cummins Diesel Generators
- Options: Auto Transfer Switch(ATS)
- Genset Type: Silent / Super Silent Type
- Voltage: 220V, 240V, 440V 460V And Other Voltage Is Optional
- Warranty: 18 Months
- Engine Brand: Cummins
- Cummins Diesel Engine Parts
Technical Parameters:
PRODUCTS DETAILS
| DIESEL GENERATOR SET | |
| Genset Model | TG163CSD6 |
| Prime Power | 148KVA/118KW |
| Standby Power | 163KVA/130KW |
| Rated Voltage (V) | 220 |
| Rated Frequency (Hz) | 60 |
| Rated Speed (RPM) | 1800 |
| Power Factor (COS¢) | 0.8 (lagging) |
| ENGINE DATA | |
| Engine Brand | Cummins |
| Engine Model | 6BTAA5.9-G2 |
| No. of Cylinders | 6 |
| Cylinder Arrangement | In-line |
| Air intake way | Turbo |
| Governor | Electronic |
| Bore*Stroke (mm*mm) | 102*120 |
| Displacement (Liter) | 5.9 |
| Cooling System | Water-Cooled |
| Fuel Consumption (g/kw.h) | 208 |
| ALTERNATOR DATA | |
| Alternator Brand | Tecgen Stamford |
| Alternator Model | TGI274S-118 |
| Connecting Type | 3 Phases and 4 Wires |
| Number of Bearing | Single |
| Production Grade | IP23 |
| Altitude | ≤ 1000m |
| Exciter Type | Brushless, Self-exciting, AVR & 100% Copper Winding Wire |
| Insulation Class | H |
| Telephone Influence Factor (TIF) | ≤ 50 |
| Telephone Harmonic Factor (THF) | ≤ 2% |
| Voltage Regulation, Steady State | 1.00% |
| Transient State Voltage | ≤ -15% ~ +20% |
Customization:
Cummins Diesel Generators
Tecgen Cummins Genset, Model Number: TGC, is a reliable and cost-effective choice for your power generation needs. This diesel power generator set is certified by ISO / CE / SASO / CIQ, and comes with a minimum order quantity of 1 SET. You can negotiate with us for the price, and the package will be Plywood case / Foam and PE film package. The delivery time is 15 Working Days, and the payment terms are T/T / L/C. With 300 units available per month, the engine brand is Cummins, the frequency is 60Hz, and the power output is 25kVA--2500kVA. Optional Auto Transfer Switch(ATS) is also available, and the warranty is 18 Months.
We also offer genuine Cummins diesel generator parts and Cummins diesel engine parts, ensuring the best quality and durability of our products.
Support and Services:
Cummins Diesel Generators Technical Support and Service
Cummins diesel generators provide reliable, efficient and cost-effective power solutions for a wide variety of applications. Cummins diesel generators offer a full range of technical support and service options, from installation and commissioning to long-term maintenance and repair.
- Installation and Commissioning: Cummins provides installation and commissioning support to ensure that your diesel generator is set up correctly and running reliably.
- Maintenance and Repair: Cummins offers ongoing maintenance services and emergency repair services to keep your diesel generator running smoothly and reliably.
- Technical Support: Cummins provides technical assistance and support to help you resolve any issues with your diesel generator.
- Parts and Accessories: Cummins provides genuine parts and accessories to keep your diesel generator running efficiently and reliably.
