Frequency 50hz Cummings Gen Sets 18kw 22kw 32kw Prime Power Output
| Place of Origin | China |
|---|---|
| Brand Name | Tecgen Cummins Genset |
| Certification | ISO / CE / SASO / CIQ |
| Model Number | TGC |
| Minimum Order Quantity | 1 SET |
| Price | Negotiation |
| Packaging Details | Plywood case / Foam and PE film package |
| Delivery Time | 15 Working Days |
| Payment Terms | T/T / L/C |
| Supply Ability | 300 Units Per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power Output | 20kVA--2500kVA | Engine Brand | Cummins |
|---|---|---|---|
| Warranty | 18 Months | Frequency | 50Hz/60Hz |
| Voltage | 380V, 400V, 415V And Other Voltage Is Optional | Alternator Brand | Stamford / Leroy Somer / Tecgen |
| Genset Type | Open / Silent Type | Options | Auto Transfer Switch(ATS) |
| Highlight | frequency 50hz cummings gen sets,18 kw cummings gen sets,cummins 22kw diesel generator |
||
Product Description
Cummins Diesel Generators Frequency 50Hz 18KW 22KW 32KW Prime Power Output
Product Description:
Cummins Diesel Generators
Cummins Diesel Generators are a reliable and efficient source of power for a variety of applications. Whether you need standby power for your home or business, or a portable power source for your outdoor events, Cummins Diesel Generators are the perfect solution.
Tecgen Power Generators Features:
1, Output range: 5kVA to 3000kVA Heavy Duty diesel generator.
2, Different brands of engine, alternator and controller as options
3, Coupled with Stamford alternator, Leroy Somer alternator, Marathon alternator or Tecgen Power alternator
4, Open type, silent type, super silent type or mobile type generator.
5, CE, ISO9001-2008, SONCAP, SASO and SGS certified
6, Starter System with maintenance-free battery
7, Control Panel with Key Start (Power Switch)
8, With 100% fire-resistant sound attenuating sponge
9, 10% of rate output of overload for 1hours in every 12hours
10, Spare parts are easy to get from worldwide market with much cheaper price
11, Perfect after-service network
12, Both 50Hz and 60Hz
13, Chint circuit breaker
14, Three-phase output meets differing requirements
15, ATS ( auto transfer switch for city power and generator power ) / AMF (auto mains failure) /parallel running for option
16, Large fuel tank ensure continuous running.
17, Anti-Vibration Mounted
18, Industrial silencer and flexible exhaust hose
19, 0-110% load test for each unit before delivery
20, Guarantee for 18 months or 1500 hours (accord to whichever comes first) from ex-factory date
Technical Parameters:
| Genset Model | TG25C/S | TG30C/S | TG45C/S | |
| Rated Power | KW/KVA | 18/23 | 22/28 | 32/40 |
| Standby Power | KW/KVA | 20/25 | 24/30 | 36/45 |
| Rated Voltage | V | 400/230V or Others | ||
| Speed | RPM | 1500 | ||
| Rated frequency | Hz | 50 | ||
| Engine Model | 4B3.9-G11 | 4B3.9-G1 | 4BT3.9-G1 | |
| Engine Prime Power | KW | 20 | 24 | 36 |
| Displacement | L | 3.9 | 3.9 | 3.9 |
| Governor | Mechanical | Mechanical | Mechanical | |
| Cylinder | QTY | 4 | 4 | 4 |
| Bore*Stroke | mm*mm | 102×120 | 102×120 | 102×120 |
| Fuel Consumption 100% Load | L/h | 5.6 | 6.5 | 9.1 |
| Alternator Model | TGI184S-18 | TGI184S-22 | TGI184S-32 | |
| Voltage Regulation | AVR | |||
| Excitation Method | Brushless | |||
| Open Type Size | mm | 1600x800x1200 | 1600x800x1200 | 1700x800x1200 |
| Open Type Weight | kg | 750 | 790 | 870 |
| Silent Type Size | mm | 2200x1000x1300 | 2200x1000x1300 | 2300x1000x1300 |
| Silent Type Weight | kg | 1100 | 1150 | 1230 |
Applications:
Cummins Diesel Generators - TGC Model
Brand Name: Tecgen Cummins Genset
Are you looking for a reliable power source for your industrial, marine or emergency needs? Look no further than Tecgen Cummins Genset - the perfect solution for all your power needs. Our TGC model is a top-of-the-line diesel power generator set that offers unparalleled performance and efficiency.
Model Number: TGC
Our TGC model is a highly versatile diesel power generator set that can be used in a variety of applications. It is suitable for use in industrial settings, marine vessels, as backup power for buildings, and as emergency power in case of power outages.
Customization:
Customization Service for Tecgen Cummins Genset
Brand Name: Tecgen Cummins Genset
Model Number: TGC
Place of Origin: China
Certification: ISO / CE / SASO / CIQ
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Plywood case / Foam and PE film package
Delivery Time: 15 Working Days
Payment Terms: T/T / L/C
Supply Ability: 300 Units Per Month
Engine Brand: Cummins
Options: Auto Transfer Switch(ATS)
Alternator Brand: Stamford / Leroy Somer / Tecgen
Genset Type: Open / Silent Type
Frequency: 50Hz/60Hz
