36kVA 29kW Perkins Generator Set With Silent Enclosed Canopy

36kVA Diesel generator 29kW Perkins generator set with silent enclosed canopy

60Hz Diesel Generator Set Powered by Perkins 404D-22TG Water cooled Diesel Engine

1. Perkins Diesel Engine: Renowned brand offering reliable performance.
2. Alternator Options: Original Stamford, Leroy Somer, Meccalte, or Tecgen alternators available.
3. Cooling System: Equipped with a 50C original factory radiator for efficient cooling.
4. Digital Controllers: Choose from DEIF, Deepsea, or ComAp digital controllers for advanced control.
5. MCCB Breaker: Reliable options available from Aisikai, Delixi, CHINT, or ABB brands.
6. ATS Options: Aisikai, Suyang, ABB, or Schneider ATS available for automatic transfer switching.
7. Fuel Tank: Choose between a genset with a built-in base fuel tank or an integrated fuel tank.

36kVA Diesel Generator General Features:

(1) The silent canopy is constructed using durable cold-rolled sheet metal, providing enhanced structural strength.

(2) Our spraying plastics undergo a thorough pre-treatment process of pickling and phosphating, ensuring long-lasting paint color even when exposed to outdoor conditions for up to five years.

(3) Canopy color can be customized according to the customer's preference.

(4) Rigorous testing is conducted at 50%, 75%, 100%, and even 110% load capacity to ensure optimal performance and reliability.

(5) The base frame features a forklift mouth for easy loading and unloading, facilitating transportation and setup.

(6) Customized logos can be added upon the customer's request, applicable for orders of five units or a full container.

36kVA Diesel Generating Set Specifications:

Diesel Generator Advantages:

A. Quadruple security protection system, featuring an ultra-clear LCD display for intelligent detection, easy operation, and unattended operation.

1. High water temperature protection:
   Automatic shutdown protection when the water tank temperature exceeds 98 degrees Celsius.
2. Overcurrent protection:
   Alarm and shutdown when the load exceeds the rated current.
3. Overload protection:
   Alarm and shutdown when the load exceeds the rated power.
4. Low oil pressure protection:
   Low oil pressure alarm when the engine oil level is low.

B. Durable pure copper motor:
The generator is equipped with a high-density pure copper coil, providing strong electrical conductivity, high power conversion rate, and stability. The thickened copper wire windings and component gaskets enhance overall performance.

C. Remote control via mobile phone/computer:
The unit's operating status can be remotely diagnosed in advance through cloud server data analysis.

FAQ:

Q: Do you offer OEM service?
A: Yes, we provide OEM service.

Q: What is your payment term?
A: Our payment term is 20% T/T in advance, with the remaining payment due before shipment. Alternatively, we accept irrevocable L/C.

Q: What is your lead time?
A: Typically, our lead time is around 30 days after receiving the deposit or original L/C. However, if your order includes special design requirements, the delivery time may be longer.

Q: What certificates do you have?
A: We hold CE and ISO certificates. Additionally, we can apply for specific certificates based on the requirements of different countries, such as SONCAP for Nigeria, CIQ for Egypt, SASO for Saudi Arabia, and more.

Q: What is your MOQ?
A: Our minimum order quantity is 1 piece or unit.

Q: Which port do you often use for exports?
A: We usually use Fuzhou Port for exports, but we can accommodate customer requests for alternative ports.

Q: How to choose the power?
A: To determine the required power, you should consider the total power consumption of your equipment and take into account the current requirements.

Q: What is the difference between Prime power and Standby power?
A: Prime power refers to the continuous power output that can be sustained for 12 hours, allowing for a 10% overload for one hour within each 12-hour running period. Standby power, on the other hand, represents the maximum output limit for emergency use, strictly prohibiting overloading.

Q: What about the warranty?
A: We provide a warranty of 18 months or 1500 hours (whichever comes first) from the ex-factory date. During the warranty period, our company will supply free spare parts for any issues caused by production or raw material quality, except for damageable parts of the diesel engine resulting from customer's incorrect operation. After the warranty expiration, our company offers cost-effective parts maintenance for the generator set.
