20kVA 16kW Silent Power Generator Set FAWDE Diesel Engine And Tecgen Brushless Alternator
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Production Capacity | 300units Per Month | Alternator Brand | Tecgen Brushless |
|---|---|---|---|
| Rated Output Genset | 20kVA / 16kW | Engine Brand | FAWDE |
| Noise Level | 68dB(A)@7m | Frequency | 50Hz/60Hz |
| Equipment Options | ATS, Water Heater | Phase | 3 Phase / 4 Wire |
| Highlight | 20kVA silent power generator,16kW silent power generator,FAWDE silent diesel generator |
||
Product Description
20kVA 16kW Silent Generator Set with FAWDE Diesel Engine and Tecgen Brushless Alternator
Product Description:
Silent Power Generators
Silent Power Generators are essential for providing backup power in case of emergencies or power outages. These generators are designed to run quietly and efficiently, making them suitable for both residential and commercial use.
Features:
Silent Power Generators Features:
- Product Name: Silent Power Generators
- Noise Level: 68dB(A)@7m
- Alternator Brand: Tecgen Brushless
- Phase: 3 Phase / 4 Wire
- Equipment Options: ATS, Water Heater
- Production Capacity: 300units Per Month
Technical Parameters:
| Technical Parameter for Diesel Generator | Genset Model | TG22FW |
| Prime Power | 20kVA/16kW | |
| Standby Power | 22kVA/18kW | |
| Frequency | 50Hz | |
| Rated Voltage | 400V | |
| Power Factor | 0.8 | |
| Engine Brand | FAWDE | |
| Engine Model | 4DW91-29D | |
| Alternator Brand | Tecgen | |
| Alternator Model | TGI184S-16 | |
| Engine General Data | Engine Power(kW) | 21 |
| Cyl / Arrangement | 4L | |
| DSPL(L) | 2.54 | |
| Bore×Stroke (mm×mm) | 90x100 | |
| Speed Governor | Mechanical | |
| Fuel Consumption (g/kw.h)) | ≤230 | |
| Alternator Data | Model | TGI184S-16 |
| Brand | Tecgen Stamford | |
| Rate Output | 20kVA/16kW | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Protection Grade | IP 23 | |
| Control System | Brand | DEIF |
| Model | SGC420 | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| Alarm | ||
| Optional brand | Deepsea, Smartgen and Others |
Applications:
- Brand Name: Silent Genset
- Model Number: TG22FWS
- Place of Origin: China
- Certification: ISO / CE / SASO / CIQ
- Minimum Order Quantity: 1 Unit
- Price: Negotiation
- Packaging Details: Foam and PE film package / Plywood case
- Delivery Time: 15 Working Days
- Payment Terms: T/T or L/C
- Supply Ability: 300 Units Per Month
- Engine Brand: FAWDE
- Rated Output Genset: 20kVA / 16kW
- Phase: 3 Phase / 4 Wire
- Noise Level: 68dB(A)@7m
- Frequency: 50Hz/60Hz
Customization:
Customized Services for Silent Power Generators
Thank you for choosing Silent Genset as your preferred brand for power generation. Our TGFW model, proudly made in China, is a top-of-the-line product with numerous certifications such as ISO, CE, SASO, and CIQ.
To ensure safe transportation, our packaging includes a foam and PE film package or a plywood case. We also offer flexible payment options through T/T or L/C, and our supply ability is up to 300 units per month.
Our Silent Power Generators operate at both 50Hz and 60Hz frequencies, making them suitable for various applications and locations. The alternator brand, Tecgen Brushless, guarantees high efficiency and reliability.
