17kVA FAWDE Silent Diesel Generator 13kW Enclosed Genset For Home Back Up Power
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product | FAWDE Diesel Generator | PRP | 12kW / 15kVA |
|---|---|---|---|
| STP | 13kW / 17kVA | Engine Model | FAWDE 4DW81-23D-YFD10W |
| Alternator | Tecgen / Stamford / Leroy Somer / Mecc Alte | Genset Type | Silent Enclosed |
| Option Type | Copy Denyo Silent Canopy | Fuel Tank Capacity | 8 Hours Or 24 Hours Optional |
| Highlight | 17kVA silent generator for home,FAWDE silent diesel generator,13kw silent diesel generator |
||
Product Description
17kVA FAWDE Diesel Generator 13kW Silent Enclosed Genset for Home Back-up Power
Product Description:
Introducing our backup 17kVA FAWDE Silent Diesel Generator Set, the ultimate power solution for uninterrupted performance. Engineered with precision and built to last, this generator set offers exceptional reliability and efficiency. With its advanced features, versatile options, and numerous advantages, it is the ideal choice for various applications.
Key Features:
- Reliable Power Output: The 17kVA capacity ensures a consistent power supply, providing peace of mind during outages or in remote locations.
- FAWDE Xichai Engine: Equipped with a high-performance FAWDE Xichai diesel engine, delivering reliable power and fuel efficiency for long-term usage.
- Silent Operation: The silent enclosure minimizes noise levels, making it ideal for residential areas or noise-sensitive environments.
- User-Friendly Controls: The intuitive control panel allows for easy operation and monitoring of the generator's parameters, ensuring convenience and hassle-free usage.
- Robust Construction: Built with durable materials and a sturdy frame, this generator set is designed to withstand challenging conditions and ensure long-lasting performance.
Options:
- Automatic Transfer Switch (ATS): Seamlessly switches the power source from grid to generator during power outages, ensuring uninterrupted power supply without manual intervention.
- Remote Monitoring: Enables remote monitoring of the generator's performance and status, providing real-time updates and alerts for enhanced convenience.
17kVA Diesel Generator Technical Specifications:
| 17kVA Silent Genset Specifications | |||||
| Model | Engine | Alternator | Controller | Output(STP) | |
| TG17FWS | 4DW81-23D-YFD10W | TGI164S12 | DEIF SGC-420 | 17kVA | |
|
Remark: (1) Payment Terms: FOB Fuzhou Port (2) Delivery: 15 working days (3) Payment method: 30% deposit, 70% before delivery (4) Price Valid time: 30 Days (5) Option: Integrated Fuel Tank, Water Heater, ATS, PMG Generator, SYNC Function, 12/24 Hours Fuel Tank, 3000 hours Spare Parts
|
|||||
| General Date of FAWDE 17kVA Land-base Diesel Generator Set | |||||
| Engine Model | 4DW81-23D-YFD10W | ||||
| Alternator Mode | TGI164S12 | ||||
| Rated Output | 17kVA | ||||
| Rated Speed | 1500 RPM | ||||
| Frequency | 50 HZ | ||||
| Rated Voltage | 220 / 380V | ||||
| Rated Current | 22.8A | ||||
| Breaker | 63A Aisikai Breaker | ||||
| Power Factor | 0.8 | ||||
| Genset Phase | 3 phase, 4 – wire connection | ||||
| Fuel Tank | 8 running hours | ||||
| Noise level dB(A) @7m | 70dB(A) | ||||
| Net Weight | 650KGS | ||||
| Genset size | L2000 * W900 * H1000mm | ||||
| Voltage regulation rate | ≤±1% | ||||
| Random voltage variation | ≤±1% | ||||
| Frequency regulation rate | ≤±5% | ||||
| Random frequency variation | ≤±0.5% | ||||
| General specification of Engine for FAWDE 17kVA Land-base Diesel Generator Set | |||||
| Manufacture | FAWDE JIEFANG | ||||
| Model | 4DW81-23D-YFD10W | ||||
| Rated Output/Speed | 17KW/1500RPM | ||||
| Standby Output/Speed | 19KW/1500RPM | ||||
| Aspiration | Natural ASP | ||||
| Speed Governor | MECH or Electric | ||||
| Engine Type | 4 cylinders in line | ||||
| Bore X Stroke | 85*100mm | ||||
| Displacement | 2.27 L | ||||
| Compression ratio | 17:1 | ||||
| Cooling system | Forced Water Cooling Cycle | ||||
| Rated speed | 1500rpm | ||||
| Fuel Consumption/rated output | 3.4 L / h | ||||
| Fuel Consumption/standby output | 3.7 L / h | ||||
| Starter motor | D.C. 24V Electric starting | ||||
| Alternator (Dynamo) | AC24V | ||||
| General data of Alternator for FAWDE 17kVA Land-base Diesel Generator Set | |||||
| Alternator Model | TGI164S12 | ||||
| Manufacture | Fujian Tecgen Power Co., Ltd | ||||
| Rate Output | 15kVA | ||||
| Rated voltage(V) | 220 / 380V | ||||
| Voltage regulation | AVR ± 1.0 % | ||||
| Working Altitude | ≤1000 | ||||
| Control System | Brushless Self Excited | ||||
| Bearing | Single Bearing | ||||
| Insulation System | Class H | ||||
| Protection | IP23 | ||||
| Power factor | 0.8 | ||||
| Winding connection | 3 phase, 4 – wire connection | ||||
| Standard configuration of onshore diesel generator set | |||||
| Aluminum water tank | 50℃ | ||||
| Controller Panel | DEIF SGC-420 | ||||
| Battery | Varta Maintenance free Battery | ||||
| Silencer | Included | ||||
| Dry type air filter, fuel filter, oil filter | |||||
| 24V D.C automatic battery charger | |||||
| Max. 50 degree celsius radiator | |||||
| Batteries, rack and cable | |||||
| Ripple flex exhaust pipe, flange and muffler | |||||
Advantages:
- Dependable Backup Power: Keep your essential appliances and systems running during outages, ensuring uninterrupted productivity and comfort.
- Versatile Applications: Suitable for residential backup power, commercial establishments, construction sites, and outdoor events, catering to a wide range of power needs.
- Fuel Efficiency: The FAWDE Xichai engine optimizes fuel consumption, reducing operating costs and environmental impact.
- Quiet Operation: The silent enclosure minimizes noise, allowing for a peaceful environment during operation.
- Durability and Longevity: Engineered with high-quality components, this generator set is designed to withstand rigorous usage and deliver reliable performance over an extended lifespan.
Usage:
- Residential Backup Power: Ensure continuous power supply for essential appliances, lighting, and HVAC systems during outages.
- Commercial Applications: Power small businesses, offices, and retail establishments to maintain operations and minimize financial losses during power interruptions.
- Construction Sites: Provide reliable power for construction equipment, tools, and temporary lighting, ensuring uninterrupted progress and productivity.
- Outdoor Events: Power outdoor events, concerts, or festivals, enabling a seamless and enjoyable experience for attendees.
Choose our backup 17kVA FAWDE Xichai Silent Diesel Generator Set for reliable, efficient, and quiet backup power. Experience uninterrupted performance and peace of mind when you need it the most.
