Continuous Single Phase Silent Generator Set Silent Diesel Genset 21kVA With 850L Fuel Tank
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Genset Type | Soundproof | Engine Brand | ISUZU |
|---|---|---|---|
| Engine Model | JE493DB-04 | Engine Power | 21kW @ 1500rpm |
| Genset Output | Prime 17kW / 21kVA | Voltage | 240V/230V/220V/110V |
| Output Type | Single Phase | Fuel Tank Capacity | 850L Large Fuel Tank (24 Hours) |
| Highlight | 850L silent generator set,21kVA silent generator set,21kVA Silent Diesel Genset |
||
Product Description
Continuous single phase silent generator set silent diesel genset 21kVA with 850L fuel tank
Standard Features:
- Model: TG23JIS-1
- Output Type: Single Phase
- Rated Voltage: 240V/230V/220V/110V selectable
- Frequency: Stable 50Hz output
- Speed: 1500rpm for efficient operation
- Power Capacity: Prime Power of 17kW / 21kVA, Standby Power of 19kW / 23kVA
Key Features:
- Silent Design: Engineered for minimal noise emission, suitable for noise-sensitive environments.
- Large Fuel Tank: Equipped with an 850L fuel tank for extended runtime and reduced refueling frequency.
- Stable Performance: Delivers consistent power output with low voltage fluctuations.
- High Power Factor: PF 0.8 ensures efficient power utilization.
- Easy Operation: User-friendly controls for simplified operation and maintenance.
21kVA ISUZU Diesel Powered Generator Specifications:
| Single Phase ISUZU Diesel Power Generator Technical Datasheets | ||||||
| Genset model | TG23JIS-1 | |||||
| Genset Type | Silent | |||||
| Rate Voltage | 240V/230V/220V/110V | |||||
| Frequency | 50Hz | |||||
| Speed | 1500rpm | |||||
| Output Type | Single Phase | |||||
| P.F(COS) | P.F. 0.8 | |||||
| Prime Output Current | 91.3A | |||||
| Prime Power | 17kW / 21kVA | |||||
| Standby Power | 19kW / 23kVA | |||||
| Engine | Brand | ISUZU | ||||
| Model | JE493DB-04 | |||||
| Alternator | Brand | Stamford | ||||
| Model | SOL2-M1 | |||||
| Controller | Brand | Smartgen | ||||
| Model | HGM6110N | |||||
| Fuel Tank Capacity | 850L | |||||
| Genset Weight | 630kgs | |||||
| Genset Dimensions | L2080 * W 880 * 1100 | |||||
| ISUZU Diesel Engine Data | ||||||
| Brand | Isuzu | |||||
| Engine Model | JE493DB-04 | |||||
| Number of Cylinders | 4 Cylinder in Line | |||||
| Cycle | 4-troke | |||||
| Aspiration | Natural Intake | |||||
| Displacement | 2.585L | |||||
| Compression ratio | 18.2L | |||||
| Bore×Stroke | 93*102mm | |||||
| Speed | 1500rpm | |||||
| Prime Power | 21kW | |||||
| Standby Power | 24kW | |||||
| Speed Governor | MECH or Electrical | |||||
| Cooling System | Forced water cooling cycle | |||||
| Starting system | DC Motor | |||||
| Fuel Consumption at 100% Load | 207g/kwh@1500rpm | |||||
| Stamford Alternator Data | ||||||
| Brand | Stamford | |||||
| Model | SOL2-M1 | |||||
| Frequency/speed | 50HZ/1500RPM | |||||
| Rate Output | 22.9kVA | |||||
| No. of Phase | Single Phase, 3 Wire | |||||
| Exciter type | Single bearing, Brushless, Self-excited with AVR | |||||
| Power factor | 0.8 | |||||
| Insulation Grade | H | |||||
| Protection Grade | IP23 | |||||
| Working Condition | Below 1000m | |||||
| Bearing | Single | |||||
| Coupling | Direct | |||||
| Voltage adjust range | ≥5% | |||||
| Voltage regulation NL-FL | ≤±1% | |||||
| DEIF Controller System | ||||||
| Controller | Brand | Smartgen | ||||
| Model | HGM6110N | |||||
| Function | Auto Mains (Utility) Failure | |||||
| Static with auto. battery charger | ||||||
| Emergency stop push button | ||||||
| ATS & RS485 Connection | ||||||
| CAN Functions | ||||||
| Diesel Generator Output ranges & Brand Options | ||||||
| Prime Power (kW) | Diesel Engine | AC Alternator | Controller | Type | ||
| 17kW ~ 1260kW | Cummins | Leroy Somer | DEIF | Open/Silent | ||
| 10kW ~ 300kW | Weifang Ricardo | Tecgen | Mebay | |||
| 16kW ~ 600kW | Deutz | Marathon | DEIF | |||
| 7kW ~ 64kW | Yangdong |
Tecgen
|
||||
| 7kW ~ 76kW | Quanchai | |||||
| 18kW ~ 3000kW | Weichai | |||||
| 8kW ~ 800kW | SDEC | |||||
| 12kW ~ 320kW | FAWDE | |||||
| 18kW ~ 1200kW | Yuchai | |||||
| 11kW ~ 104kW | Beinei Aircooled | |||||
| 7kW ~ 1800kW | Perkins | Stamford | DEEPSEA | |||
| 6.8kW ~ 2000kW | Caterpillar | Caterpillar | Caterpillar | |||
| 6.8kW ~ 2000kW | FG Wilson | FG Wilson | FG Wilson | |||
| 17kW ~ 30kW | Isuzu | Mecc Alte | ComAp | |||
| 210kW ~ 818kW | VMAN | Tecgen | Tecegn | |||
| 6kW ~ 2000kW | Chinese Engines | Smartgen | ||||
Usage:
Ideal for residential, commercial, and industrial applications where a reliable and continuous power supply is crucial. Whether it's powering essential home appliances or critical equipment in a factory, this silent generator set is the perfect solution.
Advantages:
- Long-lasting Durability: High-quality components and robust construction ensure long-term reliability.
- Efficient Fuel Consumption: Optimized engine design for maximum fuel efficiency.
- Automatic Protection: Equipped with advanced safety features to protect against overloads and short circuits.
- Eco-friendly: Low emissions contribute to a greener environment.
Options:
- Customizable Output Configurations: Available in multiple voltage options to meet specific power requirements.
- Additional Accessories: Including transfer switches, cables, and other accessories for enhanced functionality.
FAQ:
- Q: What is the noise level of this generator set?
A: The silent design ensures minimal noise emission, making it suitable for noise-sensitive environments. - Q: How long can the generator run on a full tank of fuel?
A: Depending on the load and operating conditions, the 850L fuel tank can provide extended runtime, reducing the need for frequent refueling. - Q: Is the generator set easy to operate?
A: Yes, the user-friendly controls and intuitive interface make it easy to operate and maintain.
