47kVA Backup Generator Ricardo Diesel Generators With Ats & Breaker & Charger
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Usage | Backup Use | Frequency | 50Hz |
|---|---|---|---|
| Engine Brand | Ricardo | Engine Model | ZH4105D |
| Alternator Model | TGI224S34 | Controller | Smartgen HGM6120N |
| ATS | 100A | Breaker | Delixi Breaker |
| Highlight | Ricardo Diesel Generators with Breaker,47kVA Backup generator,Ricardo Diesel Generators with ATS |
||
Product Description
47kVA Backup generator ricardo diesel generators with ats & breaker & charger
Product Description: Weifang Ricardo Diesel Engine Generator - 47kVA Backup Generator
Standard Attributes:
• A robust Weifang Ricardo diesel engine boasting a standby output of 47kVA
• Steady 50Hz frequency for uninterrupted power supply.
• A 220/380V rated voltage, ensuring compatibility across a range of applications.
• An efficient forced water-cooling system for peak engine performance.
Primary Features:
• A top-notch alternator sourced from Copy Stamford, guaranteeing dependable power generation.
• An automatic voltage regulator (AVR) for a steady voltage output.
• Hushed operation, producing only 72db(A) of noise at a 7-meter distance.
• A resilient and compact design, making it suitable for both indoor and outdoor settings.
47kVA Backup Generator Specifications:
| Technical Parameter for Ricardo Engine Genset | Genset Model | TG47NS |
| Prime Power | 34kW/43kVA | |
| Standby Power | 38kW/47kVA | |
| Frequency | 50Hz | |
| Rated Voltage | 220/380V | |
| Rate Current | 64.6 A | |
| Power Factor | 0.8 | |
| Governor | MECH OR ELECTRIC | |
| Noise level (7m) | 72db(A) | |
| Engine Brand | RICARDO | |
| Engine Model | ZH4105D | |
| Alternator Brand | Copy Stamford | |
| Alternator Brand | TGI224S34 | |
| ATS | 100A Wall Mounted ATS Box | |
| Dimension | Open: L1600 x W800 x H950mm | |
| Silent: L2200 x W1000 x H1150 | ||
| Fuel Tank Capacity | 90L | |
| Engine General Data | Engine Brand | RICARDO |
| Engine Model | ZH4105D | |
| Rated Output | 44kW | |
| Rated Speed | 1500rpm | |
| Number of Cylinders | 4 | |
| Cylinder arrangement | In-line | |
| Displacement (L) | 3.76 | |
| Aspiration | Turbocharged | |
| Bore×Stroke (mm×mm) | 105x118 | |
| Compression Ratio | 17:1 | |
| Cooling | Forced Water Cooled | |
| Fuel Consumption at 100% load(L/H) | 10.5 | |
| Alternator Data | Model | TGI224S34 |
| Brand | Copy Stamford | |
| Rate Output | 34kW | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Bearing | Single | |
| Voltage Regulator | AVR | |
| Protection Grade | IP 23 | |
| Steady StateVoltage Regulater | 1% | |
| Opetion | Leroy Somer, Marathon, Mecc Alte and Chinese brand Brushless alternator | |
|
Control System |
Brand | Smartgen |
| Model | HGM6120N | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| ATS Connection | ||
| Optional brands | Deepsea, ComAp, Mebay | |
| Battery Capacity | 12/24V Varta Maintenance free Battery | |
| Cooling System | Water-cooled, 50℃ radiator with Cooper | |
| Circuit breaker | Delixi Brand 160A Breaker | |
| Auto Transfer Switch | 63A ATS | |
| Genset Options | Output Socket | |
| Integrated Fuel Tank | ||
| Trailer & Silent Canopy for Genset | ||
| Sync Panel | ||
| Water Heater & Engine Heater | ||
| Engine Brand Options | ||
| Cummins, Perkins, Weifang Ricardo, Yangdong, Quanchai, FAWDE, Weichai, Deutz, SDEC, Yuchai, Isuzu, Doosan, VMAN, Mitsubishi, MTU, Googol, Shanghai Engine | ||
Application:
The Ricardo generator is perfectly suited for hospitals, banks, data centers, and other vital installations where an uninterrupted power supply is crucial. Thanks to its muscular Chinese diesel engine and cutting-edge features, it guarantees continuous power delivery in emergency situations.
Benefits:
• A cost-effective backup power solution.
• Straightforward maintenance and operation, thanks to a user-friendly control system.
• Prolonged service life and minimal maintenance expenses.
• Eco-conscious, producing low emissions.
Enhanced Options:
• An integrated fuel tank, extending operation time without the need for frequent refueling.
• A trailer and silent canopy, enabling effortless transportation and significantly reduced noise levels.
• A synchronization panel, allowing for parallel operation with other generators, maximizing your power output.
• Additional engine and water heaters, ensuring optimal performance even in cold weather conditions.
FAQs:
• Q: What is the standby power rating of the Weifang Ricardo backup generator?
A: The standby power rating stands at 38kW/47kVA, ideal for backup power requirements.
• Q: Can I rely on this Ricardo diesel engine generator for continuous use?
A: Absolutely. The TG47NS is crafted for both prime and standby power applications, making it a suitable choice for continuous operation.
• Q: How much fuel does the generator consume?
A: At 100% load, the fuel consumption rate is 10.5L/H, ensuring efficient fuel utilization.
• Q: Is the Ricardo generator hassle-free to maintain?
A: Yes, its user-friendly control system and minimal maintenance requirements make it a breeze to keep running smoothly.
The TG47NS, backed by its Weifang Ricardo diesel engine and robust backup capabilities, is the ideal choice for your power backup needs. Whether for your business or home, the Ricardo generator ensures a dependable power supply during emergencies.
