50Hz 3 Phase Silent Genset 55KW 69kVA For Consistent Power Supply

50Hz 3 phase diesel generator silent mounted generator set fir consistent Power Supply

Product Description:

Weichai Diesel Generator is a perfect choice for industrial purposes. It is highly reliable and delivers efficient performance. This generator set is driven by a diesel engine and features a rated frequency of 50Hz. It has a low noise level of 68dB(A) and fuel consumption rate of 230g/kw.h. The rated power of the generator set is 50KW. It is easy to install and operate and is highly reliable, delivering consistent performance. With its robust construction and advanced technology, this generator set is designed to meet the highest standards of quality and safety. It is ideal for a wide range of applications and offers a cost-effective and reliable power solution.



Features:

• Product Name: Weichai Diesel Generator
• Type: Diesel Generator
• Fuel Consumption: 230g/kw.h
• Standby Power: 55KW / 69kVA
• Rated Voltage: 220, 230, 240, 380, 400, 415V
• Noise Level: 68dB(A)
• Speciality: Emergency Diesel Generator
• Designed: China Diesel Engine Generator

Technical Parameters:

Technical Specification:
MAX 55kW Weichai DG Genset Specification
Genset Model	TG69WC	TG69WCS
	Open	Silent
Frequency	50Hz
Voltage	400/230V
Phase	3
Rate Current	90.9A
Prime Power	50kW / 63kVA
Standby Power	55kW / 69kVA
Engine Model	WP4.1D66E200
Alternator Model	TGI224S50
Controller	HGM6120N
Weight & Dimensions
Length (mm)	1800	2300
Width (mm)	850	980
Height (mm)	1360	1460
Weight (kgs)	1000	1500
Engine Specification
Brand	Weichai
Engine Model	WP4.1D66E200
Prime/Standby power	60kW / 66kW
Injection	Indirect
Aspiration	Turbocharged
No. of cylinders	4
Bore of Stroke (mm)	105 x 118
Displacement (L)	4.087
Cooling	water
Compression Ratio	17.3:1
Engine Oil capacity (L)	6.7
Coolant Capacity ( In radiator)	6.7
Governor	Electric
Air Filter	Dry Element
Fuel consumption	at 50Hz
100% Load (L/h)	13.7
75% Load (L/h)	10.3
50% Load (L/h)	6.8
25% Load (L/h)	3.4
Alternator Specification
Brand	Tecgen Power
Model	TGI224S50
Rate Output	63kVA
Pole	4
Winding Connections	Star
Insulation Class	H
Enclosure	IP23
Altitude (m)	≤1000
Voltage Regulator	AVR
Steady State Voltage Regulator	1%
Bearing	Single
Controller System
Brand	Smartgen
Model	HGM6120N
Functions	Control with AMF module
	Static with auto. battery charger
	Emergency stop push button
	ATS Connection
OPTIONAL EQUIPMENTS
ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts

Applications:

We cooperate with famous diesel engine, such as Cummins, Perkins Deutz, Lovol, Doosan, SDEC, Ricardo, Isuzu, FAW, Yangdong, Weichai, MTU, etc.

The generators are equipped with advanced brushless alternator with optional Stamford, Leroy Somer, Marathon, Tecgen, Mecc alte.

To ensure its consistent working, efficient engine cooling system is provided with a 50°C radiator and a fan with high-quality steel thickness canopy from 2 mm to 6 mm.

Moreover, it is also equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen, ComAp and MEBAY.

To reduce the noise and improve the engine's efficiency, a turn-back type of air inflow and air outlet is designed.

In addition, the generator set is equipped with high density sound-absorbing material for both sound insulation and fireproofing. 12V/ 24V DC battery with charger, 10-12 hours fuel tank with fuel indicator, a high protect class control box and power output box with waterproof, electric leakage protect and breaker are also provided.

For user's convenience, the generator has a beautiful and practical design. Their bottom holes are designed for forklift, and there are water outlets and oil outlets for easy maintenance. Double open doors on both sides of the gensets are also featured.

The products include various types such as silent, supper silent, soundproof, trailer type, and container type, and all meet the main standards such as GB/T2820, ISO8528, IEC34, CE, EPA Tier4 standard.

Customization:

Brand Name: Tecgen Weichai Diesel Generator
Model Number: TG69WCS
Place of Origin: Fuzhou, China
Certification: ISO / CE / SASO / CIQ
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Plastic film package or Polywooden Package
Delivery Time: 15 Working Days
Payment Terms: T/T / L/C
Supply Ability: 300 Units Per Month
Type: Diesel Generator
Fuel Consumption: 230g/kw.h
Rated Power: 50KW / 63Kva

Max Power: 55kW / 69kVA
Noise Level: 68dB(A)
Rated Voltage: 220, 230, 240, 380, 400, 415V

Tecgen Weichai Diesel Generator is a high quality silent genset. It is certified by ISO / CE / SASO / CIQ, and its fuel consumption is 230g/kw.h. It is equipped with 50KW rated power, and the noise level is only 68dB(A). There are multiple rated voltages available, such as 220, 230, 240, 380, 400, 415V. It is widely used as a reliable power source for many applications. It can withstand harsh environments and is easy to maintain.

Packing and Shipping:

The Weichai Diesel Generator will be packaged and shipped with the following steps:

• The generator will be securely packaged in a cardboard or wooden box, depending on the size of the generator.
• The package will be sealed with tape and labeled with the generator’s model name.
• The package will then be loaded onto a truck or cargo ship for delivery.
• Upon delivery, the package will be unloaded from the truck or cargo ship and inspected for any damage.
• If no damage is found, the package will be delivered to the customer.

FAQ:

Q1: What is the Brand Name of the Weichai Diesel Generator?

A1: The Brand Name of the Weichai Diesel Generator is Tecgen Weichai Diesel Generator.

Q2: What is the Model Number of the Weichai Diesel Generator?

A2: The Model Number of the Weichai Diesel Generator is TG69WCS.

Q3: Where is the Weichai Diesel Generator made?

A3: The Weichai Diesel Generator is made in Fuzhou, China.

Q4: What certifications does the Weichai Diesel Generator have?

A4: The Weichai Diesel Generator has ISO / CE / SASO / CIQ certifications.

Q5: How many units of Weichai Diesel Generator can be supplied per month?

A5: The Weichai Diesel Generator can be supplied up to 300 units per month.
