50HZ 50KVA 40KW Silent Weichai Power Generator Set With Stamford Type Brushless Alternator
| Place of Origin | China |
|---|---|
| Brand Name | Weichai Power |
| Certification | CE/SONCAP/FCC/SGS |
| Model Number | TG55WP |
| Minimum Order Quantity | 1 Unit |
| Price | Negotiation |
| Packaging Details | Plywood case Package or Plastic film package in container |
| Delivery Time | 15-20 working days after received deposit |
| Payment Terms | T/T, L/C |
| Supply Ability | 400 Units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Diesel Generator Set | Type | Silent Type |
|---|---|---|---|
| Engine Brand | Weichai Power | Alternator Brand | Tecgen |
| Control System | AMF/ATS | Output Type | AC Single Phase/Three Phase |
| Conditions Of Use | Land Use | Cooling Method | Water Cooling |
| Ambient Temp | ≤40 C | Genset Color | Color Is Optional |
| Highlight | 50KVA Power Generator Set,Stamford Brushless Alternator Power Generator Set,40KW Power Generator Set |
||
Product Description
50HZ 50KVA 40KW Silent Weichai Power Generator Set With Stamford Type Brushless Alternator
1) Engine:Weichai Power diesel engine, Water-cooled
2) Alternator: Tecgen Stamford Typle Brushless Alternator
Brushless H class insulation, Self excitation, IP 23 protection, AVR regulator,THF < 5%,low radio interference.
3) 3 phase 4 wires / 1 phase 2 wires
4) Three phase voltage Available :208V/220V/230V/240V/380V/390V/400V/415V/440V/460V/480V
Single phase available:100-250V
50KVA 40KW Silent Power Diesel Generator Set
50HZ 3 Phase 400V
| Technical Parameter for Diesel Generator | Genset Model | TG55WP |
| Prime Power | 50kVA/40kW | |
| Standby Power | 55kVA/44kW | |
| Frequency | 50Hz | |
| Rated Voltage | 400V | |
| Power Factor | 0.8 | |
| Engine Brand | Weichai | |
| Engine Model | WP2.3D48E200 | |
| Alternator Brand | Tecgen | |
| Alternator Model | TGI224S-40 | |
| Engine General Data | Engine Power(kW) | 44 |
| Cyl / Arrangement | 4L | |
| Air Intake way | Turbo | |
| Bore×Stroke (mm×mm) | 89x92 | |
| Speed Governor | Electrical | |
| Fuel Consumption (g/kw.h)) | 220 | |
| Alternator Data | Model | TGI224S-40 |
| Brand | Tecgen | |
| Rate Output | 50kVA/40kW | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Protection Grade | IP 23 | |
| Control System | Brand | Smartgen |
| Model | HGM6120N | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| Alarm | ||
| Optional brand | Deepsea, Deif, ComAp | |
| Starting Voltage | 24V | |
Genset Feature:
Engine
· Heavy duty diesel engine
· Four stroke, water cooled
· 12V and 24V stater and charge alternator
· Cooling radiator and fan
· Maintenance free battery including ract and cable
· Flexible fuel connection hoses and manual oil sump drain valve
· Exhaust silencer
Alternator
· Brushless, single bearing, flexible disc
· Insulation class: H
· Protection class: IP23
· Self-exciting and Self-regulation
Canopy
· All canopy designed with modular principles
· All metal canopy parts painted by electrostatic polyester power paint
· Soundproof design ensure that the noise level be controlled in small scope
· Convenient to lift and move
· Easy to maintenance and operate
Base Frame
· Base frame including position for forklift and crane
· Integral fuel tank
· Daily fuel tank continuously supply for 8-24 hours
· Fuel tank easy to maintain and clean
· Anti-vibration pads are flexed between engine and alternator.
Control System
Control, monitor and protect the Generator Set including:
· High water temperature
· Low oil pressure
· Over and under speed
· Over current
· Under/Over generator voltage
· Start and stop failure
· Low and high battery voltage
· Charge fail
· Emergency stop
Service:
1)Before-sale Service:
We provide detailed product technical parameters for equipment choosing and system designing.
2)Service quality assurance:
Our sale staffs are all experlence and professional ,who can provide the most proper system design and optimized equipment for the customers.
3)After sale maintenance service:
We create files for end user and provide them follow-up service, regular return visit and permanent maintenance.
4)Spare parts supply:
We provide all kinds of spare parts and technical support.
