18kW Baudouin Engine Generator Set Backup Electric Genset With Stamford For Home Use
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Usage | BACKUP | Product | Silent Baudouin Diesel Generator |
|---|---|---|---|
| Speed | 1500rpm | Engine Brand | Weichai Baudouin |
| Engine Model | 4M06G25/5 | Generator Model | Stamford SOL2-M1 |
| Prime Genset Output | 18kW | Generator Type | Open Type, Silent Type, Super Silent Type, Trailer Type |
| Highlight | 18kW Baudouin engine generator set,home use Baudouin engine generator set,backup Baudouin engine generator set |
||
Product Description
18kW Baudouin engine generator set backup electric genset with Stamford for home use
Baudouin 18kVA Diesel Engine Generator Set Technical Datasheet
Overview:
Introducing the Baudouin 18kW Diesel Generator, model TG25WBS, a silent-type generator designed for reliable and efficient power generation. With its robust construction and advanced features, it's the perfect solution for a wide range of applications.
Technical Specifications:
- Engine: Baudouin 4M06G25/5 diesel engine with a natural intake system, delivering prime power of 23kW and standby power of 25kW.
- Alternator: Stamford SOL2-M1 alternator, brushless and self-excited with AVR, providing a rate output of 23kVA.
- Controller: DEIF SGC-420 controller with auto mains failure function, ensuring seamless power transition during utility failures.
- Output: Available in multiple voltage options, including 440V, 415V, 400V, 380V, 230V, 220V, and 110V.
- Dimensions & Weight: Compact dimensions of L2200 x W1000 x H1400 and a weight of 800kgs for easy transportation and installation.
Key Features:
- Ultra-silent design for discreet operation, making it suitable for noise-sensitive environments.
- Forced water cooling cycle ensures efficient engine cooling, extending the generator's lifespan.
- MECH or electrical speed governor for precise control of engine speed.
- IP23 protection grade offers added safety and reliability.
Backup 18kW Baudouin Diesel Engine Generator Set Parameters:
| 18kW Baudouin Diesel Engine Generator Technical Datasheets | ||||||
| Genset model | TG25WBS | |||||
| Genset Type | Silent | |||||
| Rate Voltage | 440V//415V/400V/380V/230V/220V/110V | |||||
| Frequency | 50Hz | |||||
| Speed | 1500rpm | |||||
| P.F(COS) | P.F. 0.8 | |||||
| Prime Output Current | 38.0A | |||||
| Prime Power | 18kW / 23kVA | |||||
| Standby Power | 20kW / 25kVA | |||||
| Engine | Brand | Weichai Baudouin | ||||
| Model | 4M06G25/5 | |||||
| Alternator | Brand | Stamford | ||||
| Model | SOL2-M1 | |||||
| Controller | Brand | DEIF | ||||
| Model | SGC-420 | |||||
| Genset Weight | 800kgs | |||||
| Genset Dimensions | L2200 * W 1000 * 1400 | |||||
| Baudouin Diesel Engine Data | ||||||
| Brand | Baudouin | |||||
| Engine Model | 4M06G25/5 | |||||
| Number of Cylinders | 4 Cylinder in Line | |||||
| Cycle | 4-troke | |||||
| Aspiration | Natural Intake | |||||
| Displacement | 2.3L | |||||
| Compression ratio | 17.5:1 | |||||
| Bore×Stroke | 89*92mm | |||||
| Speed | 1500rpm | |||||
| Prime Power | 23kW | |||||
| Standby Power | 25kW | |||||
| Speed Governor | MECH or Electrical | |||||
| Cooling System | Forced water cooling cycle | |||||
| Starting system | DC Motor | |||||
| Fuel Consumption at 100% Load | 225g/kwh@1500rpm | |||||
| Stamford Alternator Data | ||||||
| Brand | Stamford | |||||
| Model | SOL2-M1 | |||||
| Frequency/speed | 50HZ/1500RPM | |||||
| Rate Output | 23kVA | |||||
| No. of Phase | 3 Phase, 4 Wire | |||||
| Exciter type | Single bearing, Brushless, Self-excited with AVR | |||||
| Power factor | 0.8 | |||||
| Insulation Grade | H | |||||
| Protection Grade | IP23 | |||||
| Working Condition | Below 1000m | |||||
| Bearing | Single | |||||
| Coupling | Direct | |||||
| Voltage adjust range | ≥5% | |||||
| Voltage regulation NL-FL | ≤±1% | |||||
| DEIF Controller System | ||||||
| Controller | Brand | DEIF | ||||
| Model | SGC-420 | |||||
| Function | Auto Mains (Utility) Failure | |||||
| Static with auto. battery charger | ||||||
| Emergency stop push button | ||||||
| ATS & RS485 Connection | ||||||
| CAN Functions | ||||||
| Diesel Genset Output ranges & Brand Options | ||||||
| Prime Power (kW) | Diesel Engine | AC Alternator | Controller | Type | ||
| 17kW ~ 1260kW | Cummins | Leroy Somer | DEIF | Open/Silent | ||
| 10kW ~ 300kW | Weifang Ricardo | Tecgen | Mebay | |||
| 16kW ~ 600kW | Deutz | Marathon | DEIF | |||
| 7kW ~ 64kW | Yangdong |
Tecgen
|
||||
| 7kW ~ 76kW | Quanchai | |||||
| 18kW ~ 3000kW | Weichai | |||||
| 8kW ~ 800kW | SDEC | |||||
| 12kW ~ 320kW | FAWDE | |||||
| 18kW ~ 1200kW | Yuchai | |||||
| 11kW ~ 104kW | Beinei Aircooled | |||||
| 7kW ~ 1800kW | Perkins | Stamford | DEEPSEA | |||
| 6.8kW ~ 2000kW | Caterpillar | Caterpillar | Caterpillar | |||
| 6.8kW ~ 2000kW | FG Wilson | FG Wilson | FG Wilson | |||
| 17kW ~ 30kW | Isuzu | Mecc Alte | ComAp | |||
| 210kW ~ 818kW | VMAN | Tecgen | Tecegn | |||
| 6kW ~ 2000kW | Chinese Engines | Smartgen | ||||
Applications:
Ideal for hospitals, data centers, factories, construction sites, and other facilities that require a dependable and silent backup power source.
Why Choose Us?
- Reliable Baudouin diesel engine with proven performance and durability.
- Stamford alternator for stable and efficient power output.
- DEIF controller for intelligent power management and seamless transition during power failures.
- Customizable options to meet your specific power requirements.
Contact Us:
For more information, detailed specifications, or to place an order, please contact us today. We offer competitive pricing, exceptional customer service, and a commitment to providing reliable and efficient power solutions.
