Back Up Use Diesel Generator Weifang Ricardo Genset For Emergency Power Solutions
Place of Origin | Fuzhou, China |
---|---|
Brand Name | Tecgen Power |
Certification | CE / SASO / SONCAP / COC / PVOC |
Model Number | TGR Series |
Minimum Order Quantity | 1 unit |
Price | Negotiation |
Packaging Details | Stretch film packaging or Polywooden Package |
Delivery Time | 15 - 35 Working Days |
Payment Terms | T/T, L/C |
Supply Ability | 300 Units Per Month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | Ricardo Series Genset | Type | Open / Silent / Mobile / |
---|---|---|---|
Frequency | 50Hz / 60Hz | Speed | 1500rpm / 1800rpm |
Voltage | 120/127/208/220/230/240/380/400/415/480V | Output Type | Single Phase / Three Phase |
Engine Brand | Weifang Ricardo | Genset Ranges | 10kW To 140kW |
Highlight | Emergency backup diesel generator,Emergency diesel back up generator,Emergency back up diesel generator |
Back-up use diesel generator Weifang Ricardo genset for emergency power solutions
Product Description:
Introducing the Weifang Ricardo Genset series, your ultimate solution for dependable backup power in any emergency or critical operation. Designed and manufactured with precision engineering, these diesel generator sets are tailored for a wide range of applications, ensuring uninterrupted power supply when the grid fails.
Standard Features:
- Powerful Engines: Equipped with robust engines ranging from 18KW to 160KW, each model boasts of efficient fuel combustion and low emission levels, making them eco-friendly and cost-effective.
- Mechanical Governor: All units feature mechanical governors, ensuring stable and consistent power output, ideal for sensitive equipment and processes.
- Compact Design: Compact dimensions, such as 1300x750x960mm (open type) to 3200x1130x1750mm (silent type), allow for easy installation and transportation, fitting seamlessly into various environments.
Key Features:
- High-Quality Alternators: Integrated with TGI and TGI2 series alternators, our generators provide clean and stable AC power, suitable for powering sensitive electronics and medical equipment.
- Silent Operation: Optional silent enclosures reduce noise levels significantly, making them ideal for residential, commercial, and industrial settings requiring low-noise backup power.
- Longevity & Durability: Constructed with durable materials and rigorous testing, these generators are designed for long service life and minimal maintenance.
Back-up Use diesel generator Datasheets:
Weifang Ricardo Series(50Hz) | ||||||||||||
Ricardo Diesel Generator Set Techinical Specification ( 50Hz ) | ||||||||||||
Genset Model | Genset Prime Power |
Genset Standby Power |
Engine Model | Engine Power | Cylinders | Governor | Alternator Model |
Fuel Consumption | Dimension (LxWxH) mm | |||
KVA | KW | KVA | KW | KW | L/H | Open Type | Silent Type | |||||
TG14N | 13 | 10 | 14 | 11 | M4D18 | 18 | 4L | MECH | TGI164S10 | 2.3 | 1300x750x960 | 1950x910x1170 |
TG18N | 16 | 13 | 18 | 14 | M4D18 | 18 | 4L | MECH | TGI164S13 | 2.9 | 1300x750x960 | 1950x910x1170 |
TG21N | 19 | 15 | 21 | 17 | M4D18 | 18 | 4L | MECH | TGI184S15 | 3.7 | 1300x750x960 | 1950x910x1170 |
TG25R | 23 | 18 | 25 | 20 | 490D | 22 | 4L | MECH | TGI184S18 | 4.4 | 1300x750x960 | 1950x910x1170 |
TG30R | 28 | 22 | 30 | 24 | K4100D | 30 | 4L | MECH | TGI184S22 | 5.8 | 1650x750x1050 | 2200x900x1150 |
TG33R | 30 | 24 | 33 | 26 | K4100D | 30 | 4L | MECH | TGI184S24 | 6.2 | 1650x750x1050 | 2200x900x1150 |
TG36R | 33 | 26 | 36 | 29 | K4102D | 33 | 4L | MECH | TGI184S26 | 6.6 | 1650x750x1050 | 2200x900x1150 |
TG41R | 38 | 30 | 41 | 33 | KT40D | 36 | 4L | MECH | TGI184S30 | 7.7 | 1650x750x1050 | 2200x900x1150 |
TG44R | 40 | 32 | 44 | 35 | K4100ZD | 41 | 4L | MECH | TGI184S32 | 8.5 | 1650x750x1050 | 2200x950x1220 |
TG47R | 43 | 34 | 47 | 37 | K4102ZD | 44 | 4L | MECH | TGI224S34 | 9.1 | 1650x750x1050 | 2200x950x1220 |
TG55R | 50 | 40 | 55 | 44 | ZH4105ZD | 54 | 4L | MECH | TGI224S40 | 10.3 | 1800x800x1150 | 2300x1000x1230 |
TG59R | 54 | 43 | 59 | 47 | ZH4105ZD | 54 | 4L | MECH | TGI224S43 | 10.8 | 1800x800x1150 | 2300x1000x1230 |
TG62R | 56 | 45 | 62 | 50 | N4105ZD | 56 | 4L | MECH | TGI224S45 | 11.3 | 1800x800x1150 | 2300x1000x1230 |
TG66R | 60 | 48 | 66 | 53 | ZH4105ZLD | 60 | 4L | MECH | TGI224S48 | 11.8 | 1800x800x1150 | 2400x1000x1250 |
TG69R | 63 | 50 | 69 | 55 | N4105ZLD | 62 | 4L | MECH | TGI224S50 | 12.4 | 1800x800x1150 | 2400x1000x1250 |
TG80R | 73 | 58 | 80 | 64 | R4108IZLD | 75 | 4L | MECH | TGI224S58 | 13.9 | 1800x800x1150 | 2500x1060x1290 |
TG103R | 94 | 75 | 103 | 83 | R6105ZD | 92 | 6L | MECH | TGI274S75 | 17.1 | 2300x900x1400 | 2800x1100x1460 |
TG110R | 100 | 80 | 110 | 88 | R6105AZD | 94 | 6L | MECH | TGI274S80 | 18.4 | 2300x900x1400 | 2800x1100x1460 |
TG138R | 125 | 100 | 138 | 110 | R6105AZLD | 121 | 6L | MECH | TGI274S100 | 23.1 | 2300x900x1400 | 2850x1100x1460 |
TG151R | 138 | 110 | 151 | 121 | R6105IZLD | 132 | 6L | MECH | TGI274S110 | 25.2 | 2300x900x1400 | 2850x1100x1460 |
TG176R | 160 | 128 | 176 | 141 | R6108ZLD | 155 | 6L | MECH | TGI274S128 | 29.3 | 2400x1000x1400 | 3100x1100x1700 |
TG193R | 175 | 140 | 193 | 154 | R6113ZLD | 160 | 6L | MECH | TGI274S140 | 30.9 | 2400x1000x1400 | 3200x1130x1750 |
Usage:
Whether you're in need of backup power for hospitals, data centers, factories, construction sites, or even remote communities, the Weifang Ricardo Genset series offers a reliable solution. They seamlessly switch on during power outages, ensuring continuity of operations and minimizing downtime.
Advantages:
- Instant Power Backup: With fast startup times, our generators provide immediate power backup, safeguarding your operations against unexpected power cuts.
- Fuel Efficiency: Optimized engine design minimizes fuel consumption, reducing operational costs and environmental impact.
- Versatility: Available in various power ratings, our diesel generator sets cater to diverse needs, from small businesses to large-scale industries.
Options:
- Choose from open or silent type enclosures to suit your noise level requirements.
- Customize with additional features like automatic transfer switches, remote monitoring systems, and extended fuel tanks for enhanced functionality.
FAQs:
- Q: What is the fuel consumption of a TG55R model?
- A: The TG55R model consumes approximately 10.3L/H of diesel, providing efficient and cost-effective power backup.
- Q: Are these generators suitable for sensitive electronics?
- A: Yes, equipped with high-quality alternators, our generators produce clean and stable power, safe for powering sensitive electronics and medical devices.
- Q: How does the silent type enclosure reduce noise?
- A: The silent type enclosure utilizes sound-absorbing materials and advanced acoustic design to significantly reduce noise levels, making it ideal for noise-sensitive environments.
Experience the peace of mind that comes with owning a Weifang Ricardo Genset. With its reliable performance, fuel efficiency, and versatility, our diesel generator sets are the ultimate choice for backup power solutions. Contact us today to learn more and select the perfect model for your needs.
