Weichai 320kW power genset silent power generators with ATS for residential use

Weichai 320kW power genset silent power generators with ATS for residential use

Standard Features:

Introducing the Weichai 320kW Power Genset, a silent power generator designed to meet the diverse power needs of various industries. This robust genset boasts a rated output of 320kW / 400kVA and a standby output of 352kW / 440kVA, ensuring reliable power supply even during peak demands. With a frequency of 50Hz and a rated voltage of 240/415V, it offers a three-phase, 0.8 power factor output, making it ideal for a wide range of applications.

The genset is powered by a Weichai WP13D405E200 diesel engine, a four-stroke, water-cooled, direct injection powerhouse that delivers a rated power of 368kW at 1500rpm. Featuring six cylinders with a bore and stroke of 127 x 165mm, this engine provides a displacement of 12.54 liters, ensuring efficient and smooth operation. The turbocharged and aftercooled intake system enhances performance, while the 24V DC starting method ensures easy and reliable startups.

The Leroy Somer TAL-A473-A alternator, made with 100% pure copper, offers a rated power of 320kW and an efficiency of 92.50%. With brushless, self-excitation and voltage regulation of <=±1%, it ensures stable and consistent power output. The H-class insulation provides added durability and safety.

Key Features:

• Powerful Engine: The Weichai diesel engine delivers high power and efficiency, ensuring reliable performance even in demanding conditions.
• Silent Operation: Designed for silent operation, the genset minimizes noise pollution, making it suitable for use in noise-sensitive environments.
• High Efficiency Alternator: The Leroy Somer alternator ensures maximum energy conversion efficiency, reducing energy waste and operational costs.
• Advanced Control System: The Smartgen HGM6120N control system offers comprehensive monitoring and protection features, ensuring safe and efficient genset operation.

Weichai 320kW Power Genset Specifications:

Usage:

The Weichai 320kW Power Genset is perfect for a variety of applications, including industrial, commercial, and residential use. It can be used as a primary or backup power source for hospitals, data centers, construction sites, and other critical facilities. Its silent operation and compact design make it an ideal choice for remote locations and noise-sensitive areas.

Advantage:

• Reliability: With a robust design and high-quality components, the genset ensures reliable power supply, minimizing downtime and operational disruptions.
• Efficiency: The high-efficiency alternator and powerful engine maximize energy output, reducing fuel consumption and operational costs.
• Versatility: Suitable for a wide range of applications, the genset can be customized to meet specific power requirements and operational needs.
• Ease of Maintenance: The genset is designed for easy access and maintenance, reducing downtime and extending the lifespan of the equipment.

Options:

• Integrated Fuel Tank: Provides additional fuel storage, ensuring uninterrupted power supply for extended periods.
• ATS Box / Cabinet: Automatic transfer switch system for seamless switching between power sources.
• PMG Alternator: Provides a stable and precise power output, ideal for sensitive loads.
• Trailer Type: Mobile genset with a trailer for easy transportation and deployment.
• Engine Heater and Water Heater: Ensures optimal engine performance in cold weather conditions.
• Fuel-Water Separator: Protects the engine from fuel contamination, extending its lifespan and reducing maintenance costs.

FAQ:

1. What is the rated output of the Weichai 320kW Power Genset?
   • The rated output is 320kW / 400kVA.
2. Is the genset suitable for silent operation?
   • Yes, the genset is designed for silent operation, minimizing noise pollution.
3. What type of engine powers the genset?
   • The genset is powered by a Weichai WP13D405E200 diesel engine.
4. What are the key features of the control system?
   • The Smartgen HGM6120N control system offers comprehensive monitoring and protection features, including under-speed, over-speed, battery monitoring, and more.
5. Can the genset be customized to meet specific needs?
   • Yes, the genset can be customized with various options, including an integrated fuel tank, ATS box, PMG alternator, and more.

In conclusion, the Weichai 320kW Power Genset is a reliable, efficient, and versatile silent power generator that meets the diverse power needs of various industries. With its high-quality components and advanced features, it ensures reliable power supply, minimizing downtime and operational costs. Whether you need a primary or backup power source, the Weichai 320kW Power Genset is the perfect choice for your power needs.
