40kW Ricardo Engine Generator
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product | Weifang Ricardo Generator | Frequency | 50Hz |
|---|---|---|---|
| Rate Voltage | 400 / 230V | Rate Current | 72.2 A |
| Rate Output | 40kW / 50kVA | Max Output | 44kW / 55kVA |
| Engine Model | N4105ZDS | Alternator Model | TGI224S40 |
| Type | Silent | Noise Level | 68 DB (A) |
| Highlight | 40kW ricardo engine generator,230V ricardo engine generator,50kVA ricardo generator |
||
Product Description
40kW Weifang Ricardo Diesel Engine Genset Silent Silent Genset on All Ricardo Generator Ranges
Silent Type Weifang Ricardo Diesel Generator
TECGEN silent type Ricardo generator has good acoustic performance, compact design, user-friendly and safety features. Silent type generator is becoming more popular in the industry as it's easier to install, transport and can be operated outside directly.
Key Features:
---Improved advanced air flow and ambient temperature design which assures the generator can perform its utmost capability both at 100% prime and 110% emergency standby use
---Customized built-in high performance residential muffler minimizes the noise level
---Top lifting points as standard feature
---Forklift pockets and eyelets as standard feature
---External robust steel lockable fuel inlet with electrical fuel gauge as standard feature
---User-friendly external power outlet flap
---Environmental-friendly fully bunded base fuel tank assures no oil or coolant spills onto the ground
---Earth strap fitted on all canopy doors to assure safety
---The canopy adopts a holistic disassembly structure with large size doors to assure the convenience for daily check and maintenance
---High quality outdoor powder coating to strictly protect against rusty, corrosion and ultraviolet radiation
WEIFANG RICARDO ENGINE GENERATOR TECHNICAL DATA:
| Technical Specification: | ||
| Generator Set Specification | ||
| Genset Model | TG55R | TG55RS |
| Open | Silent | |
| Frequency | 50Hz | |
| Voltage | 400/230V | |
| Phase | 3 | |
| Rate Current | 72.2A | |
| Prime Power | 40kW / 50kVA | |
| Standby Power | 44kW / 55kVA | |
| Engine Model | N4105ZDS | |
| Alternator Model | TGI224S40 | |
| Controller | Mebay DC52D | |
| Weight & Dimensions | ||
| Length (mm) | 1700 | 2350 |
| width (mm) | 850 | 1000 |
| Height (mm) | 1050 | 1300 |
| Weight (kgs) | 1000 | 1250 |
| Engine Specification | ||
| Brand | KOFO Ricardo Series | |
| Engine Model | N4105ZDS | |
| Prime power (kw) | 56 | |
| Injection | Indirect | |
| Aspiration | Turbocharged | |
| No. of cylinders | 4 | |
| Bore of Stroke (mm) | 105 x 120 | |
| Displacement (L) | 4.15 | |
| Cooling | water | |
| Compression Ratio | 17:1 | |
| Engine Oil capacity (L) | 5.5 | |
| Coolant Capacity ( In radiator) | 5.5 | |
| Governor | Mech | |
| Air Filter | Dry Element | |
| Fuel consumption | at 50Hz | |
| 100% Load (L/h) | 10.7 | |
| 75% Load (L/h) | 8.0 | |
| 50% Load (L/h) | 5.4 | |
| 25% Load (L/h) | 2.7 | |
| Alternator Specification | ||
| Brand | Tecgen | |
| Model | TGI224S40 | |
| Rate Output (kW) | 40 | |
| Pole | 4 | |
| Winding Connections | Star | |
| Insulation Class | H | |
| Enclosure | IP23 | |
| Altitude (m) | ≤1000 | |
| Voltage Regulator | AVR | |
| Steady State Voltage Regulator | 1% | |
| Bearing | Single | |
| Controller System | ||
| Brand | Mebay | |
| Model | DC52D | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| ATS Connection | ||
| OPTIONAL EQUIPMENTS | ||
| ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts | ||
FAQ (FREQUENCY ASKED QUESTION)
Question: What's your warranty period of Tecgen Generator?
Answer: Our payment terms is 1.5 year or 1500 running hours whichever comes first.
But based on some special project, we can extend our warranty period.
Question: Does your generators has global warranty?
Answer: Yes, most of our products like Cummins, Perkins, Doosan power generator enjoy the global warranty service.
And the alternator we use like Leroy somer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the aftersales service.
Question: Do you accept OEM/ODM service?
Answer: Yes, we can accept OEM & ODM service.
Question: What's your payment terms?
Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment.
Or 100% irrevocable confirmed L/C at sight.
Question: What's your delivery time?
Answer: Our normal delivery time is 7 - 15 working days.
But if your order is some special engine and alternator, then the delivery time is longer.
Question: What's the MOQ?
Answer: 1 Set
