19kW Diesel Electric Generator 4 Cylinder Diesel Fueled Generator With Automatic Voltage Regulation
| Place of Origin | Fuzhou, China |
|---|---|
| Brand Name | Tecgen Open-type Genset |
| Certification | ISO / CE / SASO / CIQ /CO |
| Model Number | TG23C |
| Minimum Order Quantity | 1 SET |
| Price | Negotiation |
| Packaging Details | Plastic film package or Polywooden Package |
| Delivery Time | 10 Working Days |
| Payment Terms | T/T / L/C |
| Supply Ability | 400 Units Per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Frequency | 50Hz | Genset Type | Open Type Diesel Generators |
|---|---|---|---|
| Number Of Cylinders | 4 CYLINDER | Speed Governor | Electric |
| Voltage Regulation | AVR | Maintenance | Easy |
| Genset Standby Ouput | 19kW / 23kVA | Voltage Range | 220-440V |
| Highlight | 19kW diesel electric generator,23kVA diesel electric generator,220v diesel fueled generator |
||
Product Description
19kW Diesel electric generator 4 Cylinder diesel-fueled generator with Automatic Voltage Regulation
Product Description:
Ricardo Generators provide reliable Open-Type Diesel Generator sets, with a 19kW/23kVA standby output powered by a Cummins Diesel Engine, consisting of 4 Cylinders and an Electric Speed Governor, running at a frequency of 50Hz, making them easy to maintain. As an industry leader in diesel-powered generator technology, Ricardo Generators are trusted by professionals worldwide.
Features:
- Product Name: Open Type Diesel Generators
- Number of Cylinders: 4 CYLINDER
- Voltage Range: 220-440V
- Genset Type: Open Type Diesel Generators
- Voltage Regulation: AVR
- Genset Standby Ouput: 19kW / 23kVA
- Diesel-Driven Generator: Cummins Diesel Genset
- Diesel-Powered Generator: DCEC Cummins Genset
Technical Parameters:
| Technical Parameter for Diesel Generator | Genset Model | TG23C |
| Prime Power | 17kW/21kVA | |
| Standby Power | 19kW/23kVA | |
| Frequency | 50Hz | |
| Rated Voltage | 1500RPM | |
| Power Factor | 0.8 | |
| Governor | Electric | |
| Engine Brand | Cummins | |
| Engine Model | 4B3.9-G11 | |
| Alternator Brand | Tecgen | |
| Alternator Brand | TGI184S17 | |
| Engine General Data | Engine Brand | Cummins |
| Engine Model | 4B3.9-G11 | |
| Rate Output (kW) | 20 | |
| Number of Cylinders | 4 | |
| Cylinder arrangement | Vertical in-line | |
| Displacement (L) | 3.9 | |
| Aspiration | Naturally Aspirated | |
| Bore×Stroke (mm×mm) | 102x120 | |
| Compression Ratio | 17.3:1 | |
| Fuel Consumption at 100% load(L/H) | 6.1 | |
| Alternator Data | Model | TGI184S17 |
| Brand | Tecgen | |
| Rate Output | 21kVA | |
| Frequency | 50Hz | |
| Altitude | ≤1000 | |
| Insulation | Class H | |
| Protection Grade | IP 23 | |
| Opetion | Leroy Somer, Marathon, Mecc Alte and Chinese brand Brushless alternator | |
|
Control System |
Brand | Smartgen |
| Model | HGM6110N | |
| Functions | Control with AMF module | |
| Static with auto. battery charger | ||
| Emergency stop push button | ||
| Alarm | ||
| Optional brands | Deepsea, ComAp, Mebay | |
| Battery Capacity | 12/24V | |
| Cooling System | Water-cooled, 50℃ radiator with Cooper | |
| Fuel Tank Capacity | 50L | |
Applications:
Tecgen Open-Type Genset TG23C is a diesel-powered open-type generator that offers maximum power output with easy maintenance and reliable operation. Powered by a high-performance diesel engine, this open-type diesel generator is capable of generating up to 19kW / 23kVA of standby power, and is designed to meet the requirements of various industries. The generator is constructed with high-quality components and offers excellent reliability and low maintenance. It is equipped with an electric speed governor for efficient operation and is certified by ISO / CE / SASO / CIQ / CO. It is also backed by a minimum order quantity of 1 SET and a competitive price with fast delivery time of 10 Working Days. Payment terms are available through T/T / L/C and 400 units per month can be supplied. With its easy maintenance and superior performance, the Tecgen Open-Type Genset TG23C is a reliable diesel-driven generator that is suitable for use in various applications.
Customization:
Customized Open Type Diesel Generators
We offer Cummins Generators, Open-Type Generator with Cummins Generators Price. Our Open Type Diesel Generators are of Brand Name Tecgen Open-type Genset, Model Number TG23C, with Place of Origin Fuzhou, China, Certification ISO / CE / SASO / CIQ /CO, Minimum Order Quantity 1 SET, Price Negotiation, Packaging Details Plastic film package or Polywooden Package, Delivery Time 10 Working Days, Payment Terms T/T / L/C, Supply Ability 400 Units Per Month, Frequency 50Hz, Maintenance Easy, Genset Standby Ouput 19kW / 23kVA, Voltage Range 220-440V, Number of Cylinders 4 CYLINDER.
Packing and Shipping:
The Open Type Diesel Generators will be packaged and shipped in a secure and safe manner to ensure the product arrives in perfect condition. The product will be individually wrapped in shock absorbent material and placed in an outer box. The box will be sealed with sturdy tape and labeled with the contents and destination address. The box will then be placed in a larger, secure shipping container, with cushioning material around it for added protection.
FAQ:
- Q: What is the Brand Name of this product?
A: The Brand Name of this product is Tecgen Open-type Genset. - Q: What is the Model Number?
A: The Model Number is TG23C. - Q: Where is this product made?
A: This product is made in Fuzhou, China. - Q: What certifications does this product have?
A: This product has ISO / CE / SASO / CIQ /CO certifications. - Q: What is the Minimum Order Quantity?
A: The Minimum Order Quantity is 1 SET.
